Functional Description and Specifications

Disconnect battery pack from tool or place the switch in the locked
WARNING
!
or off position before making any assembly, adjustments or
changing accessories. Such preventive safety measures reduce the risk of starting
the tool accidentally.
FOOTPLATE
RELEASE BUTTON
RUBBER BOOT
BLADE
CLAMP SET
SCREW
SAW
BLADE
Model Number
Voltage Rating
Stroke Length(s)
Strokes Per Minute
Charger
Voltage rating
Battery pack
11:35 AM
Page 6
Cordless Reciprocating Saw
FIG. 1
AIR VENTS
VARIABLE
SPEED
TRIGGER
BATTERY
PACK
BLADE CLAMP
RELEASE LEVER
ADJUSTABLE
FOOTPLATE
1644-24
18 V
3/4", 1 1/4" (19mm, 32mm)
n
0-2,300/min
0
BC003, 4, 6, & BC016
120 V
60 Hz
BAT025 & BAT026
BC006 charger requires 12 V DC input
NOTE: ONLY USE CHARGERS LISTED ABOVE
-6-
STROKE LENGTH/
LOCK-OFF SWITCH
BASIC BLADE
CLAMP
(Optional)
1645-24
24 V
3/4", 1 1/4" (19mm, 32mm)
n
0-2,300/min
0
BC004, 6, & BC016
120 V
60 Hz
BAT030 & BAT031
