Functional Description and Specifications

Disconnect the plug from the power source before making any
WARNING
!
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
INTAKE
AIR VENTS
FIG. 1
EXHAUST
AIR VENTS
SHAFT LOCK
WORKLIGHT
(Model RZ20 only)
KEYLESS CHUCK
DUST HOOD
(Not included,
available as accessory)
DEPTH GUIDE
LOCKING
KNOB
NOTE: For tool specifications refer to nameplate on your tool.
Spiral Saw™
SPEED
CONTROL DIAL
(Models RZ10 & RZ20 only)
(Model RZ20 only)
DEPTH GUIDE
LOCKING
SCREW
-8-
BUMP-OFF SLIDE
"ON/OFF" SWITCH
HANDLE
RELEASE
BUTTON
COVER
REMOVABLE
HARD
AUXILIARY
CONTROL
HANDLE
COLLAR
WORKLIGHT
DEPTH GUIDE
BRACKET
LOCK LEVER
DEPTH
GUIDE
