A-2
A
PPENDIX
RJ-45 Connector Pin Assignments
Figure A-1
Figure A-1 RJ-45 Connector Pin Assignments
AUI Connector Pin Assignments
Table A-1
interface) connector.
Table A-1 AUI Connector Pin Assignments
Pin
1
2
3
4
5
6
7
8
A: S
PECIFICATIONS
shows the RJ-45 connector pin assignments.
8
7
RD- 6
5
4
RD+ 3
TD- 2
TD+ 1
8
lists the pin assignments for the AUI (attachment unit
Function
Collision shield
Collision +
Transmit +
Receive shield
Receive +
Power return
Not used
Not used
Pin
Function
9
Collision –
10
Transmit –
11
Transmit shield
12
Receive –
13
+12 volts
14
Voltage shield
15
Not used
