Payload Case**
Figure 04
** The images of the items above are for illustration purpose only, and the actual item(s) packed with your Intel Falcon 8+ UAS may differ from the one(s) depicted
here depending on, for example, which payload you ordered.

Main Components

The UAS comes with the below main components:
• The Intel Falcon 8+ UAV
• The Intel Cockpit Controller
• The Intel Powerpack Batteries
• Payload
The Intel Falcon 8+ UAV
2
4
3
4
2
Figure 05
4 1
4
The payload of the Intel Falcon 8+ UAS must be placed as
shown in Figure 04. Make sure that it is placed conveniently
inside the foam bolster.
The foam bolster cover (not shown) located on top of the
payload, should be used to secure the payload when it is
transported in the Intel Falcon 8+ UAS case, while it is mounted
onto the UAV.
UAV with payload – top view:
1 Actively stabilized camera mount with gimbal and camera
2 Motor rails
3
Central unit
4 Carbon cross
