08.08.2002 / Page 2
Doc. No: 4812 713 12746

Technical data

Dimensions
Height
Width
Depth
Weight
Gross weight
Net weight
Surroundings temperature
Room temperature
maximun
Room temperature
minimum
Humidity
Relative humidity
maximun
Power connection
Voltage
Frequency
Connected load
Fuse
Drum data
Volume
Drum speed
Airflow
Capacity of laundry
Cotton max.
Easy care max.
Exhaust hose
Inner diameter
Maximum allowable
length (with 2 bows)
TRAK 6450
8560 645 20001
85
cm
59.5
cm
60
cm
33
kg
31
kg
35
˚C
5
˚C
95
%
230
V
50
Hz
2.8
kW
16
A
104
l
56 ± 3
rpm
3
120 - 160 m
/h
5
kg
2.5
kg
10
cm
4
m
Whirlpool Europe
Customer Service
Electrical components
Heating
Type
Nominal voltage
Nominal power
Heating resistances:
Connection points
Thermostats
Caution:
If one of the thermostats (TL, TH1.2)
is defective, the whole heating
element has to be changed for safety
reason !
Therefore, the thermostats are not
available as separate spare parts !
Safety thermostat (in heater) TL
Switch off (temp.)
Fluff thermostat (in heater) TH 1.2
Switch on (temp.)
Switch off (temp.)
Exhausting thermostat (in airchannel) TH 1.1
Switch on (temp.)
Switch off (temp.)
Control module Omega
Type
Fac. code
Type
Nominal voltage
Frequency
Rated currents
Motor
Heater
Drumlight
Temperature
Ambient
Storage
S E R V I C E
Aluminium mass
heating
230 + 10% / - 15% V
2500 ± 5%W
19.5 - 23 Ω
298 - 10
˚C
195 ± 7 .5 ˚C
220 ± 7 .5 ˚C
38 ± 5
˚C
53 ± 4
˚C
Electronic Timer
Flextronics max.options
4303 308 34581
N
V ± 10%
230
50 / 60
Hz
≤ 6
A
≤ 16
A
≤ 0.1
A
up to 50 ˚C
- 25 to 85 ˚C
