11.09.2000 / Page 2
Doc. No: 4812 713 12167

Technical data

Dimensions
Height
Width
Depth
Weight
Gross weight
Net weight
Surroundings temperature
Room temperature
maximun
Room temperature
minimum
Humidity
Relative humidity
maximun
Power connection
Voltage
Frequency
Connected load
Fuse
Drum data
Volume
Drum speed
Airflow
Capacity of laundry
Cotton max.
Easy care max.
Exhaust hose
Inner diameter
Maximum allowable
length (with 2 bows)
AWZ 234
8575 234 01010
85
cm
59.5
cm
56
cm
33
kg
31
kg
35
˚C
5
˚C
95
%
230
V
50
Hz
2.8
kW
16
A
104
l
56 ± 3
rpm
3
120-160
m
/h
5
kg
2.5
kg
10
cm
4
m
Whirlpool Europe
Customer Service
Electrical components
Heating
Type
Aluminium mass heating
Nominal voltage
230 +10% / -15% V
2500 ± 5%
Nominal power
Heating resistances:
Connection points 19.5 - 23
Thermostats
Caution:
If one of the thermostats (TL, TH1.2)
is defective, the whole heating
element has to be changed for safety
reason !
Therefore, the thermostats are not
available as separate spare parts !
Safety thermostat (in heater) TL
Switch off (temp.)
Fluff thermostat (in heater) TH 1.2
Switch on (temp.)
Switch off (temp.)
Exhausting thermostat (in airchannel) TH 1.1
Switch on (temp.)
Switch off (temp.)
Control module Omega
Type
Nominal voltage
Frequency
Rated currents
Motor
Heater
Drumlight
Ambient
temperature
Storage
temperature
S E R V I C E
W
298 ± 10 ˚C
195 ± 7.5 ˚C
220 ± 7 .5 ˚C
38 ± 5
˚C
53 ± 4
˚C
Electronic Timer
Flextronics max.options
230± 10% V
50/60
Hz
≤ 6
A
≤ 16
A
≤ 0.1
A
up to 50 ˚C
up to 85 ˚C
