27 .05.2004 / Page 2
Doc. No: 4812 713 14098

Technical data

Dimensions
Height
Width
Depth
Weight
Gross weight
Net weight
Surroundings temperature
Room temperature
maximun
Room temperature
minimun
Humidity
Relative humidity
maximum
Power connection
Voltage
Frequency
Connected load
Fuse
Drum data
Volume
Drum speed
Airflow
Capacity of laundry
Cotton max.
Easy care max.
Exhaust hose
Inner diameter
Maxi.allowable length
(with 2 bows)
AWZ 3303
8575 330 10030
85
cm
59.5
cm
56
cm
33
kg
31
kg
35
˚C
5
˚C
95
%
230
V
50
Hz
2.8
kW
16
A
104
l
56 ± 3
rpm
3
120 - 160 m
/h
5
kg
2.5
kg
10
cm
4
m
Whirlpool Europe
Customer Service
Electrical components
Heating
Type
Nominal voltage
Nominal power
Heating resistances:
Connecting points
Thermostats
Caution:
If one of the thermostats (TL, TH1.2)
is defective, the whole heating
element has to be changed for safety
reason !
Therefore, the thermostats are not
available as separate spare parts !
Safety thermostat (in heater) TL
Switch off temperature
Fluff thermostat (in heater) TH 1.2
Switch off temperature
Exhausting thermostat (in bottom) TH 1.1
Type
Switch on temperature
Switch off temperature
Timer
Type
Nominal voltage
Frequency
Number of steps
Stop
Heating (138 min.)
Cool down (6 min.)
Anticreasing (12 min.)
Stop
Reversing cycle
Ambient temperature
Storage temperature
S E R V I C E
Aluminium mass
heating
230 +10%/ -15% V
W ± 5%
2500
19.5 - 23 Ω
298 -10
˚C
220 ± 7 .5 ˚C
ELTH 261 P
38 ± 4
˚C
53 ± 3
˚C
Electromechanical
Eaton EC 4605
bi-directional
230 +10%/ -15% V
50
Hz
60
01
02 - 53
54 - 55
56 - 59
60
2'- 6'- 2'- 80'
5 to 75
˚C
up to 85 ˚C
