- Page 1 Quick Start Guide Super 3G Router 434T Quick Start Guide ------------------------------------------ Version: 1.0-----------------------------------------------------------...
-
Page 2: Table Of Contents
Quick Start Guide Contents 1 CHECK PACKAGE CONTENTS ......................3 2 SYSTEM REQUIREMENTS ......................... 3 3 APPEARANCE ..........................4 4 QUICK ROUTER SET-UP ........................5 1：I ........................5 NSERT THE CARD 2: C PC .......................... 5 ONNECT TO A 3: C ...................... -
Page 3: Check Package Contents
Quick Start Guide 1 Check Package Contents 3G Router DC9V 1.5A Power Adapter x1 Quick Start Guide x1 3G External Antenna（option） 2 System Requirements The recommended PC configuration for using the Router is as follows: CPU: Pentium 500 MHz or above ... -
Page 4: Appearance
Quick Start Guide 3 Appearance (Figure 1) -
Page 5: Quick Router Set-Up
Quick Start Guide 4 Quick Router Set-up Step1：Insert the SIM card Warning Before inserting or removing the SIM card, you must disconnect the device from the power adapter. If you are required to enter the PIN code, enter the correct one. If you fail to enter the correct PIN or PUK code, the network-related functions are unavailable. -
Page 6: Step 3: Connect To A Telephone Set
Quick Start Guide Step 3: Connect to a telephone set The communication quality of the telephone set can be interfered by the wireless signal. Place the telephone set one meter away from the device. (Figure 4) Step 4: Connect the external antenna (optional) Connect the external antenna cable with the antenna jack on the main unit. -
Page 7: Configure The Network Settings
Quick Start Guide (Figure 6) 5 Configure the network settings Step1: On the desktop, right-click on “My Network Places”, select “Properties”. (Figure 7) Step2: In the following pop-up window, right-click on “Local Area Connection” and select “Properties”. - Page 8 Quick Start Guide Step3: In the following window, select “Internet Protocol (TCP/IP)” option, and then click “Properties”. (Figure 9) Step4: In the following pop-up window, select “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Then click“OK”. (Figure 10) Step5: If you selected LAN connection.
- Page 9 Quick Start Guide Connection” icon in the lower right of desktop, check the wireless network status and select your wireless network. Then connect to it.】 (Figure 11) Step6: Input order “ping 192.168.1.1” and click “Enter” , it will get the following result which is showing the above configuration is successful.
-
Page 10: Configure 3G Router
Quick Start Guide 6 Configure 3G Router Step 1: Open Web Management Open Web browser, input 192.168.1.1 at Address bar, then press “Enter”. (Figure 13) Step 2: input USER and Password the following pop-up window, both input “admin” at “User name” bar and “Password” bar, then press “OK”. -
Page 11: Step 3: Intelligent Guide
Quick Start Guide (Figure 14) Step 3: Intelligent Guide Click “Quick Setup Guide” as displayed on the major interface and make use of the intelligent guide functions of the router. It enables the first time configuration of the router’s time, administrator information, internal and external network ports. -
Page 12: Step 5: Configure The System Time
Quick Start Guide (Figure 16) Click Next to Configure the System Time Step 5: Configure the System Time (Figure 17) Click “Next” to Configure 3G Mode Current time: display the system time of the router. Sync with host: make sure that the router’s time settings are consistent with those of the PC. NTP Server: set up an Internet-based time server. -
Page 13: Static Mode
Quick Start Guide STATIC Mode IP address: Static IP address provided by the ISP. Subnet mask: provided by ISP. Default Gateway: Fill in the gateway address as provided by the ISP. Primary DNS Server: Fill in the DNS server as provided by the ISP. Different areas have different DNS addresses. -
Page 14: Pppoe (Adsl) Mode
Quick Start Guide PPPOE (ADSL) Mode User Name: Fill in the Internet access account as provided by the ISP. Please place enquiries on the ISP in case of any queries. Password: Fill in the password as provided by the ISP. Please place enquiries on the ISP in case of any queries. -
Page 15: Mode
Quick Start Guide dynamic mode. 1. Please select the dynamic IP if you can automatically obtain IP addresses from the ISP. There is no need to fill in the information included in the following three columns if you select the dynamic mode. - Page 16 Quick Start Guide Under the “On-Demand” mode, the system will be connected to the network automatically in case of WAN access requests. If there are no network access requests within the specific period (idle time), the system will disconnect to the network automatically. This connection mode could effectively save network access fees for users that select to make payment by the time actually consumed.
-
Page 17: Step 7: Configure Lan Information
Quick Start Guide Step 7: Configure LAN Information (Figure 19) Click “Next” to Configure WLAN Information Intranet ports and DHCP settings IP Address: set up IP address for Intranet ports. Subnet Mask: set up masks for the Intranet. MAC Address: display the physical address of Intranet ports. DHCP Type: Select “Server”... -
Page 18: Step 8: Configure Wlan Information
Quick Start Guide Step 8: Configure WLAN Information (Figure 20) Click “Apply ” to Complete configuration Radio On/Off: switch On or Off wireless networks. If Intranet clients do not select “Enable”, they could not get Wi-Fi connectivity to the Intranet of the router. Network Mode : select standards used by wireless networks. -
Page 19: Restoring The Factory Defaults
Quick Start Guide 7 Restoring the Factory Defaults You need to reconstruct the network or you forget he changes of some parameters, you can choose to restore factory defaults and reconfigure the device. Reset: Press and hold it to restore the factory defaults. After this operation, all configurations are restored to the defaults. - Page 20 FCC STATEMENT 1. This device complies with Part 15&22/24 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
