- Page 1 Copra Moisture Tester HX-120 Operating Manual...
- Page 2 Copra Moisture Tester Safety Precautions If the safety precautions for the copra moisture tester are not observed, injuries or damage to property may result. While the safety of the product has been given considerable attention, please read the precautions in the operating manual and use the instrument properly.
-
Page 3: Table Of Contents
CONTENTS 1. Features................4 2. Specifications ..............5 3. Part Names ................. 6 4. Display ................7 5. Description of Keypad ............8 6. Directions ................9 6-1. Before Measurement ........... 9 6-2. Measurement Method ..........10 6-3. Setting the Measurement Mode ........12 6-4. -
Page 4: Features
1. Features • Measure moisture content by simply piercing with electrodes You can measure moisture content simply by piercing the sample with the electrodes. • Handheld device with large built-in display The portable handheld device features a large 76mm x 52mm display that's very easy to read. •... -
Page 5: Specifications
2. Specifications Measurement Principle : Electrical resistance Applications : Copra Standard method : ISO 665 Measurement Range : 3 to 20% Measurement Precision : Standard error 0.4% (moisture values of 10% or lower) Display : Digital (LCD) Resolution : 0.1% Operating Temperature Range : 0 to 40˚C Functions : Moisture value bias adjustment (–9.9 to +9.9%), average value,... -
Page 6: Part Names
3. Part Names <Main body> <Accessories> Connector Display Two needle probe (Cap) Shoulder strap Control Panel 1.5 V battery (AA) (6) Wrench Battery cover (back) Carrying case Operating manual... -
Page 7: Display
4. Display Description of display Item No. Name of display area Description Battery indicator Comes on when battery is depleted. Number of measurment times Displays the number of times measured. Displays the set-point value for the alarm for the upper moisture limit that Alarm set-point value was set. -
Page 8: Description Of Keypad
5. Description of Keypad • Of the numeric keys of 0 to 9, some combine numerical input and other functions. Function Power On and Off <Control panel> Bias correction Not used for this device. Average value Entering a minus input Setting of upper alarm limit Setting printer output Use for measuring. -
Page 9: Directions
6. Directions 6-1. Before Measurement 1. The unit is powered by six 1.5 V batteries (AA, alkaline). Remove the rear battery cover, place the batteries into the compartment taking care to correctly orient the positive ( ) and negative ( ) terminals. -
Page 10: Measurement Method
6-2. Measurement Method 1. Press the key to turn on the power. All elements of the LCD will be displayed for approximately three seconds. Subsequently, the “TIMES”, and “%” will be displayed. • If the display shows something other than that described above, there may be a problem with the unit. - Page 11 3. Press the key. The decimal point will blink. After about 3 seconds a “beep” will sound and the “Number of measurement times”, “Moisture value”, and “Bar graph” will be displayed. • The key on the left and the key on the right both have the same function so it doesn't matter which one you press.
-
Page 12: Setting The Measurement Mode
6-3. Setting the Measurement Mode There are two measurement modes: “Normal measurement mode” and “Continuous measurement mode”. Immediately after pressing the key and turning on the power, the unit will be set to “Normal measurement mode”. If the unit is set to “Continuous measurement mode”, measurements can be made without pressing the key for each measurement. -
Page 13: Displaying The Average Value
6-4. Displaying the Average Value When the number of measurements is from 2 to 9, and you press , the “AVE”, “average value”, and “number of measurement times” will be displayed. At this time, the “AVE”, “average value”, and “number of measurement times” remain displayed, but if you proceed to make a measurement, the “number of measurement times”... -
Page 14: How To Make Bias Adjustment
6-5. How to make Bias Adjustment The calibration (scale) for this unit was prepared by determining the relationship between the moisture of copra resulting from a drying method and the electrical resistance of the copra, and then statistically processing these results. However, depending on various conditions, there are cases where the standard measurement method and the moisture value do not agree. -
Page 15: Setting The Alarm
6-6. Setting the Alarm An upper limit moisture alarm can be set. When copra is measured having moisture higher than the set moisture value, the alarm sounds with a beeping tone. 1. Press the key. The numbers to the right of “ALARM” will blink. 2. -
Page 16: Printer Output
6-7. Printer Output [Printout example] HX-120 Measured values can be printed out by using the optional printer TIMES (VZ-330). The output content is “number of measurement times”, “moisture value”, and “average moisture value”. 1. How to set up Press the in normal measurement mode. -
Page 17: Error Display
7. Error Display When there is a problem with the unit or with the measurement conditions, the following errors will be displayed for 4 seconds, and then the power will turn off. 1. There is a problem with the temperature sensor. Servicing is required. - Page 18 3. The measurement cannot be made because the temperature of the unit is below –5°C. Bring the temperature of the unit up to the operating temperature range (0 to 40°C), and make the measurement again. 4. The measurement cannot be made because the temperature of the unit is above 50°C.
- Page 20 060160...
