  • Page 1: Operating Instructions

    DJ MIXER DJM-750MK2 pioneerdj.com/support/ rekordbox.com For FAQs and other support information for this product, visit the above site. Operating Instructions...

  • Page 2: Table Of Contents

    Contents How to read this manual Thank you for purchasing this Pioneer DJ product. Be sure to read this manual and the “Operating Instructions (Quick Start Guide)” included with the unit. Both documents include important infor- mation that you should understand before using this product.

  • Page 3: Before Start

    Features STANDARD LAYOUT This unit retains the control panel layout of the Pioneer DJ DJM series, This unit is a 4-channel DJ mixer that continues the tradition of the DJM a world standard for DJ mixers. The simple, easy-to-understand control series from Pioneer DJ, the global standard for the disco/club scene.

  • Page 4: Part Names And Functions

    Part names and functions Rear panel 1 u button (page 10 ) d AC IN Turns this unit on and off. Connect to a power outlet with a supplied power cord. Connect the power cord after all the connections are completed. 2 RETURN terminals (page 8 ) Be sure to use the supplied power cord.

  • Page 5: Control Panel

    Control Panel 1 PHONES terminal (page 10 ) 6 SOUND COLOR FX buttons (page 11 ) Connect headphones. Turns on and off SOUND COLOR FX. 1/4” stereo phone plugs and 3.5 mm stereo mini plugs are supported. 7 OFF, ON, TALK OVER selector switch (page 11 ) 2 LEVEL control (page 10 ) Turns the microphone on and off.
  • Page 6 d EQ/ISO (HI, MID, LOW) controls (page 10 ) w SEND/RETURN LEVEL control (page 12 ) Adjusts the sound quality of each channel. Adjusts the sound level of SEND/RETURN. e Channel Level Indicator (page 10 ) x Main display (page 11 ) Displays the sound level of each channel before it passes through Displays the effect name, BPM, effect parameter, etc.

  • Page 7: Connections

    ! Use the USB cable supplied with this unit when connecting this unit to a computer. ! A USB hub cannot be used. Connecting input terminals Analog player Analog player Analog player Analog player Microphone rekordbox Computer To power outlet Pioneer DJ’s DJ player Pioneer DJ’s DJ player...

  • Page 8: Connecting Output Terminals

    Connecting output terminals Headphones Mobile device Top panel of unit USB hubs cannot be used. USB port covers Rear panel Power amplifier Power amplifier Power amplifier External effector (for booth monitor) 1 Connect an external effector to the [RETURN] terminal (input terminal). 2 Be sure to use the [MASTER1] terminals for a balanced output.

  • Page 9: Connecting To The Control Panel

    1 Do not push or pull hard on the USB port cover. It could be damaged. 2 When connecting a mobile device, use the cable supplied with the device. For information on supported mobile devices, access the following Pioneer DJ site below. pioneerdj.com/support/ 3 Connect headphones to either the phone jack or the mini jack.

  • Page 10: Operation

    Operation Basic Operation Monitoring sound with headphones 1 Connect headphones to the [PHONES] terminal. Outputting sound 2 Press the [CUE] button of the channel to be monitored. 1 Press the [u] button. 3 Set the [MONO SPLIT, STEREO] selector switch. This unit turns on.

  • Page 11: Advanced Operations

    Using a microphone Advanced Operations 1 Connect a microphone to the [MIC] terminal. Using the SOUND COLOR FX function 2 Set the [OFF, ON, TALK OVER] selector switch to [ON] or [TALK OVER]. These are effects that change in association with the [COLOR] control. —...
  • Page 12 ! The [AUTO] BPM measurement range is BPM = 70 to 180. For some Using the SEND/RETURN function tracks, it may not be possible to measure the BPM correctly. If the BPM cannot be measured, the BPM value on the display flashes. In External effector and mobile devices can be used.
  • Page 13 ! For MIDI channel setting instructions, see Changing the settings on page 22 . ! For details of the MIDI messages on this unit, access the following Pioneer DJ support site. pioneerdj.com/support/ % Connect this unit to a computer or mobile device.

  • Page 14: Types Of Effects

    Types of effects Types of SOUND COLOR FX effects Effect name Descriptions [COLOR] control [PARAMETER] control Turn counterclockwise: Applies the echo Applies an echo effect, with the sound delayed effect to the mid-range only. Turning the control to the right increases DUB ECHO slightly after the original sound output several Turn clockwise: Applies the echo effect to the...
  • Page 15 REVERB ROLL This function adds a reverberation effect to the input sound. The sound being input at the point when the [ON/OFF] button is pressed ! Lowering the channel faders and cutting the input volume leaves a is recorded, and the recorded sound is output repeatedly according to delay sound.

  • Page 16: Use Rekordbox Dj

    Installing rekordbox Use rekordbox dj If you are installing rekordbox for the first time or are upgrading from rekordbox 3 or earlier, use the following procedures. If you have installed rekordbox 4 already, update it to the latest version. rekordbox Before installing rekordbox This manual mainly explains the hardware operations of this unit.

  • Page 17: Launch Rekordbox

     Installation procedure (Mac OS X) 4 Click [Close] to close the rekordbox installer. 1 Unzip the downloaded rekordbox software file. 2 Double-click the rekordbox software to launch the installer. 3 Read the license agreement, and select [Agree] if you agree to the terms.

  • Page 18: Adding Track Files To [Collection]

    If [Windows Security] appears on the screen while the installation is in 2 Select [DJM-750MK2] from the pull-down menu and progress, click [Install this driver software anyway] to continue the click [Install] in the audio driver installation screen.

  • Page 19: Using The Dvs

    Using the DVS Digital music files on a computer can be played by connecting the computer and an analog player (or DJ player) to this unit and then playing a con- trol disc on the analog player (or DJ player). 1 Install rekordbox dj on your computer beforehand.

  • Page 20: Using Applications Other Than Rekordbox Dj

    (both the individual installing the Program and any single legal Designated Nationals List or the U.S. Department of Commerce Denied entity for which the individual is acting) (“You” or “Your”) and Pioneer DJ Persons List or Entity List. By using the Program, you represent and war- Corporation (“Pioneer DJ”).
  • Page 21 This Agreement may not be modi- 750MK2_X.XXX.exe) downloaded in Obtaining the fied or amended without Pioneer DJ’s prior and express written driver software. consent, and no other act, document, usage or custom will be The driver software installation screen appears.

  • Page 22: Changing The Settings

    Changing the settings Setting preferences *: Setting upon purchase Options settings Detail setting items Setting value Descriptions Reduces sudden, unpleasant digital clipping of the master PEAK LIMITER OFF, ON* output. MASTER OUT Sets the attenuation level of the sound output from the ATT.

  • Page 23: About The Talk Over Function

    For Windows output at the same volume level as the sound input to this unit. Click [Start] menu > [All Programs] > [Pioneer] > [DJM-750MK2] > ! If the volume is not loud enough after adjusting the volume of the [DJM-750MK2 Settings Utility].

  • Page 24: Checking The Latest Information On The Driver Software

    (latency) increases. For the latest information on this unit’s dedicated driver software, access the following Pioneer DJ support site. pioneerdj.com/support/ ! Operation cannot be guaranteed when multiple units of this mixer are connected to a single computer.

  • Page 25: Additional Information

    Additional information Troubleshooting ! If something is wrong with this unit, check the following issues, and also access the Pioneer DJ site and check [FAQ] for [DJM-750MK2]. pioneerdj.com/support/ ! This unit may not operate properly due to static electricity or other external influences. In such cases, disconnect the power cord and connect it again to restore normal operation.
  • Page 26 Problem Check Remedy Sound is distorted when an analog Is an analog player with a built-in phono equalizer Connect an analog player with a built-in phono equalizer to the [LINE] terminals. player is connected to the [PHONO] connected to this unit? (page 7 ) terminals.

  • Page 27: Block Diagram

    Block Diagram LINE MUTE HEAD PHONES PHONO CH1_SEL MINI PLUG LINE PHONO MUTE CH2_SEL MASTER MASTER 1 MUTE LINE MUTE PHONO MASTER 2 CH3_SEL LINE D S P MUTE PHONO BOOTH BOOTH MUTE CH4_SEL MUTE RETURN SEND RETURN SEND MIC LEVEL MIC1 USBA_IN USB_UCOM...

  • Page 28: Trademarks And Registered Trademarks

    Trademarks and registered trademarks ! “Pioneer DJ” is a trademark of the Pioneer Corporation, and is used under license. rekordbox is a trademark or registered trademark of the Pioneer DJ Corporation. ! Microsoft and Windows are either registered trademarks or trade- marks of Microsoft Corporation in the United States and/or other countries.
