10. Blade
11. Tip Protector
18. Shield
B
D
6. Front Handle
9. Blade Guard
7. Front Switch Lever
8. Hand Guard
1. Battery-release Button
2. Rear Handle
3. Lock-off Trigger
4. Rear Switch Lever
5. Speed
Adjustment Knob
C
E1
12. Latch
13. Electric
Contacts
14. Mounting Slot
15. Ejection Mechanism
16. Lock for Handle
17. Motor Housing
