Summary of Contents for Ezviz Mini Trooper

  • Page 3: Regulatory Information

    EXCEED THE PURCHASE PRICE THE PRODUCT. EZVIZ does not undertake any liability for personal injury or property damage, as the result of product interruption or service termination cause by: a) improper installation or usage other than as requested; b) the protection of national or public interests; c) Force Majeure;...
  • Page 4 —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’...

  • Page 5: Safety Instruction

    This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada.

  • Page 6: Box Contents

    Box Contents Quick Start Mini Trooper CR123A Guide (x1) (x1) Battery (x4) Screw Kit (x1) Network Cable Metal Plate Base Station (Within Bundle) (x1) (Within Bundle) Plug type may vary according to countries, e.g. UK plug is available in the box in UK market.
  • Page 7 Overview Mini Trooper SYNC Button Lens Microphone Photoresistor LED Indicator Name Description SYNC Button Use to synchronize the camera. With the PIR (Passive Infrared), the device can detect a human body to determine when there is a possible break in and begins to record footage.
  • Page 8 LED Indicator • Steady Green: The system works properly. • Steady Blue: Device is not connected to internet. • Flashing Blue: Memory card is formatting or device starting synchronization with Mini Trooper. • Flashing Red: Exception occured. Main Button Use to start synchronization with the Mini Troopers (The synchronization lasts 2 mins).

  • Page 9: Setup Process

    Setup Process The Mini Trooper should be used with the EZVIZ Base Station. Base Station sold separately (unless in bundle). Step 1 Download the EZVIZ App - Download the App (If you already have an EZVIZ account, login to the App).
  • Page 10 Step 3 Plug in the Base Station - Plug the Base Station into the power outlet and the LED indicator will turn green, followed by light blue and then solid blue. The device will turn on within 2 minutes. Once the LED indicator on the Base Station is a solid blue, proceed to the next step.
  • Page 11 Proceed to the next step. *Note: During the 2-minute Sync Mode, you can sync up to 6 Mini Trooper cameras to the Base Station at the same time. SYNC Button Fast-Flashing Blue: Synchronization complete.
  • Page 12 Step 6 Add the base station to your EZVIZ Account - When logged into your account on the EZVIZ App, Tap the “+” on the top right of your Home page to Scan the QR Code. - Scan the QR Code on base station (located on the device label or Quick Start Guide cover), or manually enter the Serial Number.

  • Page 13: Camera Installation

    Camera Installation Step 1 Pick a clean and flat surface, indoors or outdoors. Camera range is up to 300 feet (100 m) from the Base Station (range could decrease based on environmental factors). 1' to 300 ' (0.3 m to 100 m) Step 2 Secure the metallic mount with the enclosed screw.
  • Page 14 Connect Base Station to Internet via Wi-Fi (Optional network setup) Step 1 Note Serial Number and Verification Code - Write down the serial number and verification code located on the base station. Step 2 Connect to the base station Wi-Fi. Using your mobile device or PC, look for and connect to the Wi-Fi Network named “ezviz_xxxxxx”...
  • Page 15 - Choose the “Wi-Fi Relay Internet Access” option as your connection mode. - Search for and choose your local Wi-Fi network and enter your Wi- Fi password. Press the “Save” button. - Check your Base Station Wi-Fi settings. Note: You can change your Base Station Wi-Fi Name and Password to your own preference.
  • Page 16 - Reconnect your phone to your local wifi network. Ensure your phone is connected to the same Wi-Fi network as the base station. - When logged into your account on the EZVIZ App, Tap the “+” on the top right of your Home page to Scan the QR Code.
  • Page 17 - Scan the QR Code located on the Quick Start Guide (or on the device label). Or you can manually enter the Serial Number. - Enter the base station verification code (i.e. password) from the device label and click “OK.” - Click the “Add”...
