Page 1: User Manual
USER MANUAL MODEL: FC-70R RS-232 to USB Converter P/N: 2900-300611 Rev 2 www.kramerAV.com... -
Page 2: Table Of Contents
Recycling Kramer Products Overview Defining the FC-70R RS-232 to USB Converter Connecting the FC-70R Recommended RS-232 Connection Parameters FC-70R Commands Technical Specifications Figures Figure 1: FC-70R RS-232 to USB Converter Figure 2: Connecting the FC-70R RS-232 to USB Converter FC-70R – Contents... -
Page 3: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Congratulations on purchasing your Kramer FC-70R RS-232 to USB Converter. This product is used to control HSL secured products and is ideal for: ... -
Page 4: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality Position your FC-70R away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 5: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 6: Overview
Overview FC-70R is a protocol translator from RS-232 to USB signals to allow remote control of HSL secure and non-secure products. HSL products are controlled using keyboard, mouse and touch display (KVM combiners). FC-70R translates RS-232 control commands to enable remote control on secured KVM and KVM combiners. -
Page 7: Defining The Fc-70R Rs-232 To Usb Converter
Defining the FC-70R RS-232 to USB Converter This section defines the FC-70R. Figure 1: FC-70R RS-232 to USB Converter Feature Function RS-232 Terminal Block Connects to a control device USB-B Connector Connects to a KVM or KVM combiner being controlled... -
Page 8: Connecting The Fc-70R
To connect the FC-70R, as illustrated in the example in Figure 2, do the following: 1. Connect the USB-B connector on the back of the FC-70R to the USB keyboard connection of the KVM or KVM combiner. The FC-70R receives power over this connection. -
Page 9: Recommended Rs-232 Connection Parameters
Recommended RS-232 Connection Parameters Speed – 115200bps Data bits – 8 Stop bits – 1 Parity - None Flow Control – None FC-70R - Recommended RS-232 Connection Parameters... -
Page 10: Fc-70R Commands
#define KEY_H #define KEY_I #define KEY_J #define KEY_K #define KEY_L #define KEY_M #define KEY_N #define KEY_O #define KEY_P #define KEY_Q #define KEY_R #define KEY_S #define KEY_T #define KEY_U #define KEY_V #define KEY_W #define KEY_X #define KEY_Y FC-70R - FC-70R Commands... - Page 11 #define KEY_SLASH #define KEY_CAPS_LOCK #define KEY_F1 #define KEY_F2 #define KEY_F3 #define KEY_F4 #define KEY_F5 #define KEY_F6 #define KEY_F7 #define KEY_F8 #define KEY_F9 #define KEY_F10 #define KEY_F11 #define KEY_F12 #define KEY_PRINT_SCREEN #define KEY_SCROLL_LOCK #define KEY_PAUSE #define KEY_INSERT FC-70R - FC-70R Commands...
- Page 12 #define KEY_F15 #define KEY_CONTROL_LEFT #define KEY_SHIFT_LEFT #define KEY_ALT_LEFT #define KEY_GUI_LEFT #define KEY_CONTROL_RIGHT #define KEY_SHIFT_RIGHT #define KEY_ALT_RIGHT #define KEY_GUI_RIGHT For example, to go full screen on channel 1 while using a K424F combiner, send the following command: FC-70R - FC-70R Commands...
- Page 13 #ANATL Auto scale window according to its least L CTRL | L CTRL dimension #ANATL L CTRL | L CTRL Maximize window #ANATL Undo maximize - accepted only immediately L CTRL | L CTRL after #ANATL FC-70R - FC-70R Commands...
- Page 14 #ANATL L CTRL | L CTRL Enter scale mode #ANATL Note 1: Active only in single background size mode with dual display HW Note 2: Active only in double background size mode with dual display HW FC-70R - FC-70R Commands...
-
Page 15: Technical Specifications
15.7cm x 12cm x 8.7cm (6.2" x 4.7" x 3.4") W, D, H. SHIPPING WEIGHT: 0.55kg (1.21lbs) approx. INCLUDED ACCESSORIES: Power supply OPTIONS: RK-3T rack adapter Specifications are subject to change without notice For the most updated specifications, go to our Web site at www.kramerav.com FC-70R - Technical Specifications... -
Page 17: Safety Warning
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
