Calix T07xG HGU ONT Operation
and Maintenance Guide
July 2013
#220-00589, Rev 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T072G and is the answer not in the manual?

Questions and answers

Related Manuals for Calix T072G

Summary of Contents for Calix T072G

  • Page 1 Calix T07xG HGU ONT Operation and Maintenance Guide July 2013 #220-00589, Rev 10...

  • Page 3: Table Of Contents

    DNS_Suffix ..................... 36 Security ........................37 Firewall ......................37 MAC Filter ....................... 38 IP Filter ......................39 DMZ and ALG ....................41 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 4 T072G LEDs ......................58 T073G, T076G, and T077G LEDs ................60 Chapter 3: Frequent Asked Questions ........ 63 Chapter 4: Abbreviations ............65 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 5: About This Document

    T077G, this document is applicable to them all. The differences on the management interface to the four models are identified by Notes. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 6: Revision History

    Document updated for the Web GUI access through active WAN ports with R11A CP8. Updated to include the Public Bridged WiFi configuration (for SW release 4.1.31.411 or greater). Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 7: Product Introduction

    (PON) and transmitted it to the desired format at residential or business premises. Upstream traffic is likewise transmitted to the PON network through the fiber optic cable. A single optical fiber carries both upstream and downstream traffic. Figure T072G Overview shows the T072G ports and buttons.
  • Page 8 Figure T073G Overview shows the T073G ports and buttons. Figure 2: T073G Overview Figure T076G Overview shows the T076G ports and buttons. Figure 3: T076G Overview Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 9 Figure T077G Overview shows the T077G ports and buttons. Figure 4: T077G Overview Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 10 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 11: Chapter 1: Ont Configuration

    Chapter 1 ONT Configuration This chapter describes the ONT configuration. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 12: Web Gui Access Through Lan Ports

     Gateway address: 192.168.1.1 Note: Make the configurations based on actual ONT versions. 3. Ping the ONT IP address (Default is 192.168.1.1). Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 13 Note: Do not power off the ONT while managing the ONT on the configuration management interface. Otherwise, the ONT might be damaged. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 14: Ont Login

    Note: The Web GUI access through LAN ports has two level user accounts, one is administrator level, the other is end user level. End user level has limited Web GUI. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 15: Web Gui Access Through Active Wan Ports

    Note: Web GUI access through WAN ports is disabled by default, which can be enabled by OMCI plus configuration file and TR-069. The configuration set by OMCI plus configuration file and TR-069 has no priority difference. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 16: Configuration Interface Introduction

    The right side of the page is configuration area. The content in this area changes according to the selection in navigation bar. Please refer to following sections for detail service configurations. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 17: Status

    In the Device Information page, you can view the device name, serial number, hardware version, software version, and device running time. Figure 7: Device Information Page Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 18: Lan Status

    In the LAN Status page, you can view the information of Wireless Interface and Ethernet interfaces. Figure 8: LAN Status Note: The Wireless Information pane only applies to T073G and T077G. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 19: Wan Status

    Status, Up FEC Enable, Down FEC Enable, TX Packets, Rx Packets, Tx Dropped, Rx Dropped, and Error Packets. Figure 9: WAN Status Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 20: Network

    TR-069, DSCP Remark, and DNS_Suffix. The LAN configuration is used to configure ONT maintenance address and DHCP related parameters. Figure 10: LAN Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 21 Note: Cannot set IPv4 and IPv6 address to the ONT simultaneously. After the configurations are done, click Save button to save it. Reboot the device to make the modification to take effects. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 22: Wan

    The WAN configuration is used to configure the WAN connection parameters, including WAN basic setup and WAN IP mode setup. In WAN connection list, select Create a new WAN connection. Figure 11: WAN Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 23 If Static IP is selected, it will be requested to input the IP address, netmask, gateway, Primary DNS and Second DNS address. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 24: Wi-Fi

    The Wi-Fi page is used to configure the basic wireless network parameters. Note: Wi-Fi page only applies to the T073G and T077G. Figure 12: Wi-Fi The following table describes the parameters. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 25 PIN code generated by user’s wireless card application. WPS Connect Button Enables WPS interaction. This can also be done by the WPS button on ONT hardware. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 26 Note: When WPS is enable, encryption mode must be WPA/WPA2 Personal. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 27: Public Bridged Wifi

    Follow the steps below to configure public bridged WiFi: Note: Admin-level privileges are required. 1. Create a new WAN connection and select the Public WiFi checkbox. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 28 Recommended Value Mode Auto (b/g/n) Channel Auto-selected value WiFi MAC Disable Filter SSID Broadcast Enable SSID Isolation Enable parameters Encrypt Mode OPEN Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 29 Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 30: Routing

    Routing The Routing configuration is used to configure the static routing parameters. Figure 13: Routing Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 31 After the configurations are done, click Save button to save it. Reboot the device to make the modification to take effects. Refer to Reboot Device (on page 52) or press reset button to reboot the system. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 32: Dns

    Save the configuration. Refresh Button Clear the configuration without being saved. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 33: Tr-069

    User name for ITMS Server to access ONU Connect Request Password Password for ITMS Server to access ONU After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 34: Dscp Remark

    Enable or Disable Queue Classification. Classification Order 32 rules are supported for DSCP Remark. Wan Interface Select the Wan port of the Queue management service. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 35 Delete the MAC to IP binding rule in the local gateway tables. Save Button Save the configuration. Refresh Button Clear the configuration without being saved. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 36: Dns_Suffix

    Delete the MAC to IP binding rule in the local gateway tables. Save Button Save the configuration. Refresh Button Clear the configuration without being saved. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 37: Security

    Attack Protect Enables or Disables Denial of Service (DoS) Attack Prevention. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 38: Mac Filter

    Save the configuration. Refresh Button Clear the configuration without being saved. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 39: Ip Filter

    IP Filter In the IP Filter page, you can add IP filtering rules. Figure 20: IP Filter Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 40 Click this button, to add a new filtering rule for above configurations. After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 41: Dmz And Alg

    Enable DMZ Enables or Disables DMZ function DMZ IP Address Input DMZ host IP address Save DMZ Button Click to save DMZ Configuration Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 42: Application

    ONU LAN side with private addresses (like Web server, FTP server) can be accessed by external users from WAN port. Figure 22: NAT The following table describes the parameters: Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 43 Select which WAN link to use port forwarding setup List Add Button Create a new mapping rule using above port forwarding setup Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 44: Ddns

    Username Input DDNS account user name Password Input DDNS account password After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 45: Ntp

    After the configurations are done, click Save button to save it. Reboot the device to make the modification to take effects. Refer to Reboot Device (on page 52) or press reset button to reboot the system. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 46: Usb Storage

    Password for FTP service Re-enter password Re-Enter the password for FTP service After the configurations are done, click Save button to save it. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 47: Maintain

    Enter the new password again. Prompt Message The message reminds you of the password, such as birthday. After the configuration is done, click Save. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 48: Slid Configuration

    Select the SLID mode. There are modes: ASCII and HEX. Note: SLID configuration is PLOAM password. After the configuration is done, click Save. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 49: Configuration Backup

    Figure 28: Configuration Backup The following table describes the parameters: Parameters Description Parameter Description Export Config Click to backup system configuration to the file File Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 50: Configuration Restore

    Parameters Description Parameter Description Select File Select the configuration file name Import Config Click to restore system configuration from the file File Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 51: Firmware Upgrade

    Parameters Description Parameter Description Select File Select the firmware file name Upgrade button Click to upgrade the ONT firmware from the file Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 52: Reboot Device

    In this page, one can reboot the ONT Figure 31: Reboot Device The following table describes the parameters: Parameters Description Parameter Description Reboot button Click to reboot the ONT Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 53: Factory Default

    Figure 32: Factory Default The following table describes the parameters: Parameters Description Parameter Description Factory Default Click to reset the ONT to factory default Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 54: Diagnose

    IPv4 or IPv6. Start Test button Click this button to start the test Show Result button Click this button to show the test result Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 55: Log

    Click to save the log configuration into a file on the local PC Refresh button Click to refresh the log file from ONU Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 56: Language

    Figure 35: Language The following table describes the parameters: Parameters Description Parameter Description Select Language Select English or Russia from the drop-down list. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 57: Chapter 2: Leds

    The T07xG ONTs have several LEDs on the front panel to assist with installation and maintenance procedures. Note: The LEDs may temporarily display off or red while the ONT is booting. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 58: T072G Leds

    Figure T072G LEDs shows the locations of T072G LEDs. Figure 36: T072G LEDs Table T072G LED Description describes the LEDs and the signal descriptions. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 59 At least one POTS interfaces is off-hook for at least one hour All POTS interfaces are on-hook or the ONT is not ready for running POTS service Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 60: T073G, T076G, And T077G Leds

    Figure 38: T076G LEDs Figure 39: T077G LEDs Table T073G, T076G, and T077G LED Description describes the LEDs and the signal descriptions. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 61 WPS function is not enable, or system power is off WLAN Green Solid Wireless Interface enable Blink Data transmitting at wireless interface Wireless interface disable, or system power off Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 62 The received optical signal power level is above the prescribed limit Indicates that the Video optical band being received by the ONT/ONU is lower a prescribed limit. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 63: Chapter 3: Frequent Asked Questions

    1. Make sure network cable is not broken. 2. Check cable connection between ONT and PC. 3. Check the TCP/IP configuration of your PC. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 64 After the reset, ONT will be back to factory default. The default IP address/subnet mask is: 192.168.1.1/255.255.255.0. Default user name/Password is: admin/admin. Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.

  • Page 65: Chapter 4: Abbreviations

    Internet Service Provider Internet Television Local Area Network Media Access Control Network Address Translation Optical Network Unit Optical Line Terminal Passive Optical Network Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
  • Page 66 Universal Plug and Play Uniform Resource Locator Transmission Control Protocol VLAN Virtual Local Area Network VoIP Voice over IP WLAN Wireless Local Area Network Proprietary Information: Not for use or disclosure except by written agreement with Calix. © Calix. All Rights Reserved.
