6.5 TRANSMIT

Transmit measuring mode with user-friendly to measure the
transmittance of various color film and provide penetrating
light spectrum.
1. 2.
First, tap the A column. A red Measuring with the MK350S,
border will appear around the content A will turn into
the column. red when
completed.
3.
Next, tap the B column. A
green border will appear
measuring around the column. Put the
filter or sample on the light
sensor.
- 45 -
6.5 TRANSMIT
Setting the Ranges
To set the ranges, tap
the"Tool" icon in the lower
left corner. User can check
the transmittance of the
specific wave band.
4.
Processing the second
measurement, the content B
will turn into green when
measuring completed. The
transmittance data will be
displayed on the right
column of the screen.
Get transmit rate
specified wavelength range.
The spectrum graph will
display two orange dotted
lines.
min value max value
- 46 -
