5.
Tone
Circuit
IC-32D0A
Version:
TheCTCSStorectrcuit
is
composed
of iC7
and
IC8.
When
a
tone
number
is
selected,
data
is
sent
to
IC7 from the
CPU.
IC7
carries
out
aeriai/parallei
conversion
on
the data from
the
CPU
and
the
results
are
fed to tCS,
IC8
divides the
X2
frequency (3,579545MHz) by an
amount
related to
the data
from
the
CPU^ and
the output
is
fed
from
pi
n
1
.
The
CTCSS
tone output
level
is
controfled by
R42, then the signal
is
fed
to
the
TX
VCO
UNIT.
IC-3200E
Version:
The
1
750Hz
tone-burst
circuit
iscomposed
of 3CS,
Q23, and
Q24. ICS
is
preset
for
1750Hz and
outputs the tone signal
from
pin
1.
When
the
[TONE]
SWITCH
on
either the
microphone
or front
panel of the
IC-3200E
Is
pushed, ICS
generates
a tone
and 024
simultaneously
makes
a
SEND
line to
ground
level,
putting
thetransceiver
in
transmit
mode.
The 17S0Hz
tone output
Jevel
is
conIrolSed
by
R42 and
the
signal
Is
then fed to the
TX
VCO
UNIT.
TONE FREQUENCY
NO.
(Hz)
1
67.0
2
71 9
3
74.4
4
77.0
5 79,7
6
82.5
7
85,4
S 8S.5
9 91.5
10 94,8
11
97.4
12 100.0
13 103.5
14 107.2
TONE
1
FREQUENCY
NO.
(Hz)
15
110.9
16
114.8
17 118.8
18 123,0
19 127,3
i
20
131.8
21
1
136.5
22 141.3
23
146.2
24
151.4
25 156.7
_
. . .
26
1622
27 167.9
28 173.8
TONE
NO.
FREQUENCY
(Hz)
29
179,9
30 106.2
31 192,8
32
203,5
33
210.7
34
218.1
35 225.1
36 233,6
37
241.8
38 250.3
6.
Voltage Regulator CircutI
{PLL-YGR UNIT)
The
supply
voltage
for
the
PLL-YGR UNIT
includes 10
different values: 13.3V,
common
9V, 6V,
VR8V, UR8V, VT8V,
UT8V, +8V, UT13.8V, and
J8V.
These voltages are supplied
to
each
unit.
A
common
9V
from IC4 on
the
MAIN
UNIT
is
supplied
to
the
PLL-YGR
UNIT. This
9V
is
connected
to
the
emitters of
Q14
(VT8V),
Q13 (UT8V).
QIO
(VRSV),
and
Q9
(VRBV). 13.8V isconnected
to
theemittersofQII (VT13.8V)
and 012
(VT13.SV). Q9, QIO, Oil, Q12, Q13,
and
Q14
are
PNP
transistors
which
turn
ON
when
their
bases are
grounded.
The
voltage
is
fed out
from
the collectors of
each
transistor.
The
bases of
09^ 014
are controlled by
lC4and
IC3.
IC4 has seven
inverter transistors
so that
when
a
HIGH
level is
applied
to
IC4 from
IC3,
the output voltage
is
LOW.
IC3
is
composed
of
two decoders and a demultipiexer,
I
C3 produces a
4-bit binary
output
with
two
inputs
(A and
B).
This
input
is
controlled by three
signals;
SEND
(RX:
HIGH,
TX:
LOW),
TX
(RX;
LOW,
TX:
HIGH) and
BAND
A/B
(VHP;
LOW.
UHF; HIGH),
When
the
PLL
is
out of lock, the
ENABLE
TERMINAL
of
ICS
is
HIGH, and
all
output terminals are
LOW.
3-4
LOGIC CIRCUITS
3-4-1 CPU
The
CPU
on
the
LOGIC B UNIT
is
a4-bit
CMOS
CPU
with
an
LCD
driver.
The
initialization
matrix on
the
LOGIC
B UNIT
selects the version of the transceiver,
and
the
main
matrix
on
the
LOGIC
A
and
LOGIC B
UNITS
controls the functions of
the
transceiver.
The
CPU
controls the
PLL,
CTCSS
and speech
synthesizer
ci rcuit
by
means
of
serial
data through
I
C4 D
and
I
G4E
on
the
LOGIC
B UNIT.
1.
Memory
Backup
for
CPU
A
lithium battery
(BT1
on
the
LOGIC B
UNIT)
isfor
memory
backup when
the transceiver
is
turned
OFF. The
memory
backup
mode
begins
when
a pulse
is
applied to the
INTO
port
on
the
CPU,
stopping the
CPU
and
saving
memory
data.
3-4-2
LOGIC
A
UNIT
1.
Stop
Circuit
The
stop
circuit
consists
of
tC3B, iC4B, IC5B, Q7. Q6,
arid
DIO. IC3B, Q7,
and
Q8
function as a
NOR
gate.
D5 and R29
function as an
OR
gate.
IC5B
is
a Schmitt
trigger
ci rcuit
that
uses the junction voltage of
D1 as a reference
voltage.
Therefore,
if
the
5V
line
on
the
LOGIC A UNIT
is
more
than
4V,
IC5B
feeds Out
a
HIGH
level
and
the
one
shot
circuit
consisting
of
IC4C, C5,
and R28
feeds
a
pulse
to
the
INTO
port
on
the
CPU
to
cancel the
CPU
mode.
The
cathode
of
Dll
is
connected
to the
LCD
mute
port
on
the
CPU.
When
the
CPU
is
in
the stop
mode,
the
mute
port
is
H IGH
but
when
the
stop
mode
is
cancelled, the
mute
port
is
LOW.
Also,
the output
levef
from the
IC3, Q7,
and
Q3
NOR
gate
is
LOW.
ICABisabufferampiifier which drivesQZ.
if
the
supplied voltage
to
1C5
on
the
LOGIC A UNIT
drops below
3.8V, the
output
level
from 105
will
be
LOW
and
the output
level
from IC3B
will
be HIGH.
Therefore, the
CPU
will
activate
the stop
mode.
When
the
CPU
is
in
the stop
mode,
the
LCD
mute
port
on
the
CPU
is
HIGH, and
the
outputfrom
JC3B
is
LOW,
3
—
4
