PRINTER SENSOR FUNCTIONS
There are five (5) primary Sensor functions on the GEN5 Printer.
Bezel light and Keypad LEDs may indicate a Sensor-related error
condition (refer to Table 3).
Sensor
Paper Out
Paper Low
Paper Taken
Drawer Open
Printer Lid Open Located in the Print Head, Printer Open indicates that the
© 2017 JCM Global Corporation
GEN5™ Printer
Table 3 GEN5 Printer Sensor Status
Located in the Print Head, Paper Out indicates that paper is
not loaded in the GEN5 Printer.
Located in the Paper Tray, Paper Low indicates that less
than two (2) Tickets are detected in the GEN5 Printer.
Located in the Presenter Chute, Paper Taken indicates that a
Ticket remains in the Presenter Chute.
Located on the CPU Board, Drawer Open indicates that the
Printer is not seated properly in the Host Machine.
Printer Lid is open.
Location/Description
6
Part No. 960-000194R_Rev. A
