system
Designation
state
0 System initialization in
progress
1 Not ready for start
2 Starting lockout
3 Ready for start
4 On
5 Loop control active
5a Active mode
5b Drive halt
5c Command execution
7 Fault reaction active
8 Fault
Table 4.4 Description of system state transitions
system
state Designation
transition
0 START
1 UZK OK
2 ENABLE VOLTAGE
3 ENABLE OPERATION
4 DISABLE OPERATION
Table 4.5 Description of system state transitions
moog
Description
Initialization after device reset (e.g. hardware, parameter
list, drive, ....)
Initialization complete, no mains power or DC-link volt-
age less than switch-on threshold
DC-link voltage greater than switch-on threshold
Power stage enabled via hardware (ENPO and ISDSH)
and bit 14 in MDT
Power stage is enabled (bit 15 in MDT = 1) (state is
automatically run through in open-loop control mode
via SERCOS)
Current applied to motor; loop control active
The selected operation mode is active
Drive halt active (shutdown via stop ramp)
A command with a movement sequence is active; set-
points from the SERCOS master are being ignored
Fault reaction active; setpoints from the SERCOS master
are being ignored
Drive in fault state; setpoints from SERCOS master being
ignored, drive torque-free
Description
Initialization after boot-up complete
DC-link voltage greater than switch-on threshold
Communication phase 4 active; bit 15 in SERCOS control
word = 1
Communication phase 4 active; bit 15 in SERCOS control
word = 1
Communication phase 4 active; input ENPO = 0 and/or
bit 14 in SERCOS control word = 0
[ Chapter 4 ]
system
state Designation
transition
5 DISABLE VOLTAGE
6 UZK OFF
7 Fault
8 FAULT REACTION ACTIVE
9 FAULT RESET
Table 4.5 Description of system state transitions
4.6

Real-time control bits and real-time status bits

There are two configurable real-time bits in the MDT and the DT respectively. For
configurati¬on of these binary signals the following parameters are provided:
• S-0-0301, "Assignment IDN real-time control bit 1"
• S-0-0413, "IDN bit number real-time control bit 1"
• S-0-0303, "Assignment IDN real-time control bit 2"
• S-0-0414, "IDN bit number real-time control bit 2"
• S-0-0305, "Assignment IDN real-time status bit 1"
• S-0-0415, "IDN bit number real-time status bit 1"
• S-0-0307, "Assignment IDN real-time status bit 2"
• S-0-0416, "IDN bit number real-time status bit 2"
The real-time control bits and real-time status bits can be configured in phases 2, 3 and 4.
The assignment parameters contain the number of the parameter to configure for the
respective real-time bit.
With regard to configuration, note that the bit number must first be assigned (S-0-0413,
S-0-0414, S-0-0415, S-0-0416) before a corresponding IDN is assigned as the real-time
bit (S-0-0301, S-0-0303, S-0-0305, S-0-0307).
MSD Servo Drive User Manual SERCOS II
Description
Communication phase 4 active; input ENPO = 0 and/or
bit 14 in SERCOS control word = 0
DC-link voltage less than switch-off threshold
Fault event occurred (can occur in any system state)
The response configured for the fault is active (e.g. fault
stop ramp)
Fault reset by command S-0-0099
