1. Introduction

About the SBC

This product is a PICMG-compliant, full-size single-board computer with the Intel(R) 855GME chipset.
It supports the Intel(R) Pentium(R) M processor 1.6G - 2.0GHz (FSB 400 MHz) or Intel(R) Celeron(R)
M processor 1.3G - 1.5GHz (FSB 400 MHz). While accepting up to 2 GB of SDRAM, the board is
designed as an all-in-one computer coming standard with a variety of interfaces including the serial ATA
(SATA) and Gigabit LAN connectors. It also has the DVI-I and LVDS interfaces to support DualView.
It is bootable from a CF card as it has a CF card slot (Type I/II) as well.
When connecting external devices or building the system, please read this manual carefully.

Features

- The corresponding CPU is as follows :
Intel(R) Pentium(R) M processor 1.6G - 2.0GHz(FSB400MHz),
Intel(R) Celeron(R) M processor 1.3G - 1.5GHz (FSB400MHz)
- PICMG-compliant CPU board designed as an all-in-one computer standard with a variety of
interfaces such as LAN x 2 (one of which supports Gigabit LAN), VGA, DVI-I, LVDS, EIDE,
USB 2.0 x 6, serial, parallel, and PS/2 keyboard/mouse.
- Intel(R) 855GME + ICH4 chipset
- Max. 2GB DDR SDRAM, and ECC function support.
- Equipped with two channels of serial ATA (SATA) ports, capable of connecting storage devices in
RAID (0/1).
- Equipped with DVI-I and LDVS, supports Dual View.
- Incorporates an LVDS interface that can connect directly to an LCD display.
- GIGA bit LAN using Intel 82541 controller
- Equipped with a CF card slot (Type I/II), enabling boot-up from a CF card.
