3. Hardware Installations

IDE port Connector: CN4 / CN6

This product provides a bus-mastering PCI IDE interface. This interface support PIO Mode 3, PIO Mode
4, ATAPI devices (e.g., CD-ROM), and Ultra DMA/33/66/100 synchronous-DMA mode transfers. The
BIOS supports logical block addressing (LBA) and extended cylinder head sector (ECHS) translation
modes. The BIOS automatically detects the IDE device transfer rate and translation mode.
This connector supports the provided IDE hard disk ribbon cable. After connecting the single end to the
board, connect the two plugs at the other end to your hard disk(s). If you install two hard disks, you must
configure the second drive to Slave mode by setting its jumper accordingly. Please refer to your hard
disk documentation for the jumper setting.
CAUTION
- IDE secondary port cannot support by UltlaDMA66/100 mode at the time of CF card use.
- IDE secondary port can support one drive at the time of CF card use.
Table 3.3. IDE port Connector
CN4 /CN6
39
40
Pin No. Function
1 RESET
3 D7
5 D6
7 D5
9
D4
11 D3
13 D2
15 D1
17 D0
19 GND
21 DREQ
23 IOW
25 IOR
27 IORDY
29 DACK
31
IRQ
33 A1
35 A0
37 CS0
39 HD ACT
16
1
2
Pin No. Function
2 GND
4
D8
6 D9
8 D10
10
D11
12 D12
14 D13
16 D14
18 D15
20 N.C.
22 GND
24 GND
26 GND
28
ALE
30 GND
32 N.C.
34 P66DET
36 A2
38 CS1
40 GND
SPI-8550-LLVAS
