3. Hardware Installations

Main Memory Installation: DIMM1/2

This product supports two single-side or double-sided DDR200/266/333 unregistered, DIMM 184-pin
sockets for a maximum total memory of 2GB.
This product supports the following memory features:
- 184-pin DIMMs with gold-plated contacts
- 200MHz, 266MHz and 333 MHz DDR SDRAM.
- ECC function support.
- 2.5V memory only.
- Single or double-sided DIMM in the following sizes:

DDR SDRAM

DDR SDRAM improves memory performance through memory access that is synchronous with the
memory clock.
This product supports single or double-sided DIMMs in the following sizes:
Table 3.1. DDR SDRAM
DIMM size
128MB
256MB
512MB
1GB
CAUTION
All memory components and DIMMs used with this product must comply with the PC SDRAM
Specification. These include: the PC SDRAM Specification *memory component specific), the PC
Unbuffered DIMM Specification, and the PC Serial Presence Detect Specification.
14
Non-ECC configuration
16Mbit x 64
32Mbit x 64
64Mbit x 64
128Mbit x 64
SPI-8550-LLVAS
