  • Page 1 QBOX User’s Manual...
  • Page 2 Trademark: All trademarks are the property of their respective owners. Version: User’s Manual V1.0 for QBOX. P/N: 3A221HM00-000-G Symbol description: Caution : refers to important information that can help you to use QBOX better, and tells you how to avoid problems. WEEE: The use of this symbol indicates that this product may not be treated as household waste.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Introducing the QBOX Top View....................2 Left View....................2 Right View ....................3 Bottom View .....................3 Chapter 2 Placing and connecting the QBOX Placement of QBOX On the Desk ..................5 Under the Display Base................5 On the Backside of Display ..............6 Connection of QBOX Connect the Monitor ................7 Connect the USB Devices..............7...
  • Page 4 FreeMind ....................18 Education and Learning StarDict....................19 Mtpaint....................19 Multimedia Applications gThumb Picture Manager..............20 CD Recording..................20 Rhythmbox Music Player..............21 Video Player ..................21 Other Applications Smart Helper ..................22 Package Updater................22 Basic Parameter Settings..............22 Appendix - Install Windows XP in QBOX ........
  • Page 5 Safety Precaution: Before using this product, please read the safety precaution below carefully, and follow them strictly, this will increase the product’s life, and avoid some danger. to facilitate heat dissipation. please keep it away from your body to prevent discomfort or injury from heat exposure.
  • Page 6 The QBOX is a compact and easy to use desktop. It is equipped with an intuitive graphical interface and full wireless connectivity so you can use the QBOX and access the Internet at any time. This chapter includes the following information:...

  • Page 7: Top View

    The QBOX is a compact and easy to use desktop. It is equipped with an intuitive graphical interface and full wireless connectivity so you can use the QBOX and access the Internet at any time. Provided below is an introduction to each part function. 1-1 Top View Purpose Description...

  • Page 8: Right View

    1-3 Right View Purpose Description Multi-Function Card Reader Supports MMC/SD/MS memory card USB Port Connects to USB 2.0 device Modem Port Connects to telephone line. Used for dial-up Internet access via modem Network Port Standard RJ-45 network port Anti-Theft Lock Slot Connects to anti-theft lock 1-4 Bottom View Purpose...
  • Page 9 In this chapter, the placement and the connection of some neces- sary peripheral will be introduced. This chapter includes the following information:...

  • Page 10: Placement Of Qbox

    2-1 Placement of QBOX 1. On the Desk If there is enough space of your desk, you can simply put your QBOX on the tabletop as shown below, the top side is upturned. 2. Under the display If you want to save the space of your desk, this way can be used. 1.

  • Page 11: On The Backside Of Display

    3. On the Backside of Display This is a perfect way for good looking and space-saving. 1. Use four screws to fasten the bracket onto the display backside. 2. Keep the power button at the bottom, then put the QBOX into the bracket carefully. To install the bracket, your display must accord with VESA75/VESA100 standard.

  • Page 12: Connection Of Qbox

    2-2 Connection of QBOX 1. Connect the Monitor Connect the VGA cable, with VGA connectors on each end, to the VGA port on the QBOX, and the other end to a monitor. 2. Connect the USB Devices Connect USB devices to the USB port on the QBOX, for example, Mouse and Keyboard. 3.

  • Page 13: Connect The Power Cable

    2. Use the RJ-11 port. Connect the RJ-11 cable, with RJ-11 connectors at each end, to the RJ-11 port on the QBOX and the other end to the modem. Modem RJ-11 Cable 4. Connect the Power Cable power button to start.
  • Page 14 the computer will automatically launch "First Boot". This chapter will guide you through the setup and registration process, and introduces the QBOX Windows desktop to you. This chapter includes the following information : First Boot Desktop Chinese Input Method Computer My Documents Recycling Bin...

  • Page 15: First Boot

    3-1 First Boot "First Boot". This will guide you through the setup and registration process. Please follow the steps below to complete the initial setup process. 1. Set the appropriate Language then click on “Forward” to continue. 2. Scan the [Welcome] and press “Forward” to the [License Information], select “Yes” to continue. 3.
  • Page 16 4. Create a user account then click on “Forward” when done. 5. Set the Date and Time then click on “Reboot” to complete setup and reboot the system. 6. The system will go to the login screen as below, select the user and input the password to login.

  • Page 17: Desktop

    3-2 Desktop After turning on the QBOX, when you log into QBOX's pre-loaded Celavie system, the following screen will appear: Desktop Shortcuts – double-click to open the corresponding applications Hard disk Icon: Shows the hard disk connection USB disk Icon: Shows the USB disk connection Bluetooth Icon: Shows bluetooth status Puzzle Icon: Start Button, Open program menu Network Icon: Shows network connection status...

  • Page 18: Computer

    3-4 Computer 3-5 My Documents The documents is by default used for storing the user's personal documents, videos or music. Dou- ble-click the "XXX" shortcut on the desktop brings up the screen shown below. 3-6 Recycling Bin...
  • Page 19 There are many useful applications are pre-loaded in the sys- tem, this chapter describes some kinds of them to you. This chapter includes the following information:...

  • Page 20: Internet

    4-1 Internet 1. Web Browsing Please click on the “Earth” icon in the desktop toolbar or “Start” -> “Internet” -> “Firefox Web Browser” to open the web browser as shown below. 2. Files Transfer Please click on “Start” -> “Internet” -> "gFTP" from the desktop toolbar to open the gFTP client as 3.
  • Page 21 shown below. shown below.
  • Page 22 below. as shown below. is as shown below.

  • Page 23: Freemind

    below. 7. FreeMind "FreeMind" is a visualization software that uses a tree diagram to record notes. The tree structure -> “FreeMind” to run this application. The program is as shown below.

  • Page 24: Education And Learning

    4-3 Education and Learning 1. StarDict "StarDict" is a translation program. Please click on “Start” -> “Accessories” -> "StarDict" from the desktop toolbar to run this application. The program is as shown below. 2. Mtpaint "Mtpaint" is graphics painting software similar to Windows Paint and is used for drawing or editing simple graphics.

  • Page 25: Multimedia Applications

    4-4 Multimedia Applicatios 1. gThumb Picture Manager "gThumb Picture Manager" is a picture management tool with several functions. To use, please click on “Start” -> "Graphics" -> "gThumb Image Viewer" from the desktop toolbar. The program is as shown below. 2.

  • Page 26: Rhythmbox Music Player

    3. Rhythmbox Music Player "Rythmbox" is a music management program that allows music to be organized into play lists and can also stream radio broadcasts. To use, please click on “Start” -> "Sound& Video" -> “Rhythmbox Music Player” from the desktop toolbar. The program is as shown below. 4.

  • Page 27: Other Applications

    4-5 Other Applications 1. Smarthelper "Smarthelper" helps the user install commercial applications and third-party add-ons on the QBOX. To use, please click on “Start” -> “System Tools” -> "Smarthelper" from the desktop toolbar. The program is as shown below. 2. Package Updater "Package Updater"...

  • Page 28: Appendix - Install Windows Xp In Qbox

    Install Windows XP in QBOX By default, the QBOX has been installed Celavie Operating System for you. But if you do not like the operation system interface, you can install Windows XP by yourself. What kinds of hardware and software you need here : 1.
  • Page 29 4. The computer will reboot, and it will start installing Windows XP Operating System. Windows XP Professional Setup Welcome to Setup. Recovery Console, press R. ENTER=Continue R=Repair F3=Quit 5. Press <ENTER> to continue the installation. 6. Press <F8> to agree the Licensing Agreement and continue. 7.
  • Page 30 Windows XP Professional Setup The following list shows the existing partitions and unpartitioned space on this computer. Use the UP ad DOWN ARROW keys to select an item in the list. 114471 MB Disk 0 at id 0 on bus 0 on atapi [MBR] C:Partition1 [NTFS] 49999 MB <...
  • Page 31 Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two accept any interference received, including interference that may cause undesiredoperation. Warning: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
