- Page 1 NETBOX User’s Manual...
-
Page 2: Symbol Description
Trademark: All trademarks are the property of their respective owners. Version: User’s Manual V1.0 for NETBOX. P/N: 3A222V700-000-G Symbol description: Caution : refers to important information that can help you to use NETBOX better, and tells you how to avoid problems. Warning: indicating a potential risk of hardware damage or physical injury may exist. -
Page 3: Safety Notice
Safety Notice : Before using this product, please read the below safety notice carefully, this will help to extend the product’s lifecycle, and work normally. ■ When NETBOX is working, please make sure its ventilation system is working. ■ The power adapter is dissipating heat during normal use, please be sure not to cover it and keep it away from your body to prevent discomfort or injury by heat exposure. -
Page 4: Table Of Contents
TABLE OF CONTENTS Chapter 1 Introduction of NETBOX Product Overview ..................2 LED Indicator Introduction ................4 Chapter 2 Placement and connection of NETBOX Placement of NETBOX On the Desk ..................6 On the Display Back ................6 Connection of NETBOX Connect the Antenna ................8 Connect the Monitor ................8 Connect the USB Devices ..............8 Connect the Network Cable ..............9... - Page 5 The NETBOX is a compact and easy to use desktop. It features all the desktop capabilities but with a slim body design which enables your to browse the internet in a relaxable and comfortable way. This chapter introduces the following information: ■...
-
Page 6: Product Overview
NETBOX features all the desktop capabilities but with a slim body design which enables you to browse the internet in a relaxable and comfortable way. 1-1 Product Overview 1. Top View (190mm) 7.5in 2. Front Side View LLS_LED1 LLS_LED5 Name Description Headphone Port Connects to a headphone... - Page 7 3. Back Side View Name Description RF(Radio Frequency) Port Connects to antenna USB Ports Connect to USB devices Display Output Port(VGA) Connects to display device HDMI Port Connects to HDMI audio and video Network Port Standard RJ-45 network port Line Out and S/PDIF Out Port Connects to powered analog speakers or record- ing devices with optical connectors(3.5mm jack) Power Input Port...
-
Page 8: Led Indicator Introduction
1-2 LED Indicator Introduction Suspend_ Power_ HDD_ WLAN_ LLS_ LLS_ LLS_ LLS_ LLS_ Indication LED1 LED2 LED3 LED4 LED5 Boot Green Blink S0(Working Mode) Green S1(Power-Saving Mode) Green S3(Standby Mode) Blink [Press Suspend Button] S4(Hibernation Mode)& S5(System Power Off Mode) Blue, CPU Initialization Error Blink... -
Page 9: Placement Of Netbox
In this chapter, the placement and the connection of some neces- sary peripherals will be introduced. This chapter includes the following information: ■ Placement of NETBOX ■ Connection of NETBOX... -
Page 10: On The Desk
2-1 Placement of NETBOX 1. On the Desk You can install your NETBOX in the mount directly. If there is enough space on your desk, you can simply put your NETBOX with Magnet-Metal- Feet on the tabletop. 2. On the Display Back This is the best space-saving way. - Page 11 2.2. Fit the NETBOX into the bracket with power button locating at the top for easy touch. 2.3. After that, you can connect the antenna to your NETBOX. Remove the antenna before lifting up the NETBOX straight to take it out.
-
Page 12: Connection Of Netbox
2-2 Connection of NETBOX 1. Connect the Antenna Connect the antenna to the RF port of the NETBOX. You can fold the antenna and rotate it in different angle as you want. 2. Connect the Monitor Connect a monitor to the NETBOX through VGA connector or HDMI connector. 3. -
Page 13: Connect The Network Cable
4. Connect the Network Cable Connect LAN cable to the RJ-45 port, with the other end connected to a hub or switch. Switch 5. Connect the Power Cord Connect the power adapter to the power input port of the NETBOX, and push the power button to start it. -
Page 14: Chapter 3 Install Windows Os
This chapter introduces the following information: ■ Install Windows XP ■ Install Windows 7 ■ Appendix - Display Features Notice... -
Page 15: Install Windows Xp
Make sure you have these ready : 1. NETDVD. (It is an optional accessory. If there is no NETDVD in this package, you need other purchase an external USB DVD-ROM drive.) 2. NETBOX driver CD. (In this package) 3. Windows XP Install CD/Windows 7 Install CD. (Other purchase) The build-in graphics chipset of this Nettop only support upto Directx 9, can not up to Directx 10 or later, which is recommended by Microsoft WHQL, but you can install Operating System(Windows 7). - Page 16 1.4. The computer will reboot, and it will start installing Windows XP Operating System. Windows XP Professional Setup Welcome to Setup. This portion of the Setup program prepares Microsoft(R) Windows(R) XP to run on your computer. ● To set up Windows XP now, press ENTER. ●...
- Page 17 1.8. In this biggest hard disk size screen, you can press [C] to create partitions as you wish, assign them C:, D: or E: logical drive names. Windows XP Professional Setup The following list shows the existing partitions and unpartitioned space on this computer. Use the UP ad DOWN ARROW keys to select an item in the list.
-
Page 18: Install Drivers In Windows Xp
2. Install Drivers in Windows XP 2.1. When the Windows XP is completely installed, you have to install the necessary drivers before using the NETBOX. Take out the Windows XP Install CD from the DVD-ROM drive, and put the NETBOX driver CD inside. 2.2. -
Page 19: Install Windows 7
3-2 Install Windows 7 1. Install Windows 7 1.1. Push power button to turn on your computer, then press <Del> key to enter BIOS Setup. 1.2. Put the Windows 7 Install CD into the NETDVD or USB DVD-ROM drive. 1.3. Select and go to the “Boot” menu, enter “Boot Device Priority”, set the “1st Boot Device” to “USB: Optical DVD RW”, press <F10>... - Page 20 1.8. Later the setup will display the hard disk partitions of your system. If there were other systems (such as Linux) installed previously, you need select them and click “Drive options (advanced)” to delete them. When all partitions are clean, setup will display the biggest size of your hard drive.
- Page 21 To ensure that all Windows features work correctly, Windows might create an additional parti- tions for system files, so you will see a system reserved partition. Select the 70GB partition and click “Next” to continue. 1.10. From this step we start to install windows 7 into your hard disk, including copying Windows files, expanding Windows files...etc.
- Page 22 1.11. When the installation is completed, setup will prepare your compute for the first use. Then you can follow steps to select system settings, create an account, set a password...etc, until the whole process is completed and enter Windows 7 operating system. 2.
-
Page 23: Appendix - Display Features Notice
Appendix - Display Features Notice 1. Chrontel HDMI Display Settings and Scaling Some HDMI TV will display overscan mode as below, you can adjust it by using the Chrontel HDMI Tool which appears after installing “Chrontel Control Driver”, otherwise, it can also be used for the display resolution settings. - Page 24 Note: Click the “HDMI On” button in the left can close the HDMI output, you can reopen it by re-plugging the HDMI cable. 2. Display Instruction in OS(Windows XP/Vista/7) 2.1. In the Intel® Graphics Media Accelerator Driver, the VGA(D-sub) port is defined as “Monitor”, and the HDMI port is defined as “Notebook”.
- Page 25 2.3. For the VGA user, after installing VGA Driver, and rebooting into system, the VGA default Operating Mode is "Intel(R) Dual Display Clone", and the "Screen resolution" is held to “1280 x 720”. If you want to adjust the screen resolution, please follow the steps below to select the “Single Display”...
- Page 26 Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital...
