6.6

Indicator functions

NET
ID CODE
Display Functions
ZERO
NET
e1
e2
e2
F1
F2
kg
lb
pcs
e1 e2 e3 F1
PT TOTAL
the weighing system (including load) is stable
the weight shown is negative
the weight shown is within the zero range
the display is showing the net weight
displayed weight shown is in range 1 (option multi range)
displayed weight shown is in range 2 (option multi range)
displayed weight shown is in range 3 (option multi range)
Fork 1 / setpoint 1 is activated ( option relay output)
Fork 2 / setpoint 2 is activated ( option relay output)
displayed shows weight is kilograms
displayed shows weight is pounds
number displayed represent number of pieces on the scale
low bat indicator
kg
lb
pcs
F2
PCS KG/LB
CLR
