3.4.2 H. ADJ. Menu
Sets head adjustment parameters.
▲
MEC. ADJ
H.MNTE
When the
(1) Head adjustment pattern print (H ADJ PATTERN)
Prints an adjustment pattern to be used for head adjustment.
Press the
# H ADJ PATTERN
> NOZZLE OK?
<Parameter (Choice entry)>
- NOZZLE
- HEAD ADJ1
- HEAD ADJ2
- LEFT/RIGHT
- HEAD POS
- HEAD POS
- INK POS R
- ADJ1-1
- ADJ1-2
- ADJ1-3
- ADJ2-1
- ADJ2-2
(2) Carriage movement (MOVE CARRIAGE)
Used to move the carriage when adjusting an installed head.
Cap=Move the carriage to the cap position (do not perform capping).
# MOVE CARRIAGE
> HOME
<Parameter (Choice entry)>
- HOME
- CAP
- CENTER :
- WIPE
Section 3 Maintenance Mode Menu Operations and Functions
▼
H. A DJ
RESET
key is pressed, head adjustment parameters can be adjusted.
key during print to stop the printing.
: Prints a nozzle check pattern.
: Prints a head adjustment pattern.
: Prints a head adjustment check pattern.
: Prints a left/right position adjustment pattern.
: Prints a head position adjustment pattern.
: Prints a head position adjustment pattern.
: Prints a reciprocating adjustment pattern R.
: Prints an left/right position adjustment pattern of
HEAD ADJ1.
: Prints an inter-head position adjustment pattern of
HEAD ADJ1.
: Prints a reciprocating adjustment pattern of HEAD
ADJ1.
: Prints phase, left/right, and inter-head adjustment
patterns of HEAD ADJ2.
: Prints a reciprocating adjustment pattern of HEAD
ADJ2.
: Detects home position and move the carriage to the home position.
: Moves the carriage to the capping position.
Moves the carriage to the center.
: Moves the carriage to the wiping position.
SIIT CONFIDENTIAL
3-19
