Frico PFSE4 Original Instructions Manual

Pf smart series fan convector
Hide thumbs Also See for PFSE4:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Original Instruction Manual
SE
.... 9
FR
.... xx
GB
.... 19
IT
.... xx
NO
.... xx
NL
.... xx
Original instructions
PF Smart
DE
.... xx
PL
.... xx
ES
.... xx
RU
.... xx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFSE4 and is the answer not in the manual?

Questions and answers

Related Manuals for Frico PFSE4

Summary of Contents for Frico PFSE4

  • Page 1 Original instructions PF Smart ..xx ..xx ..xx ..9 ..19 ..xx ..xx ..xx ..xx ..xx...
  • Page 2 Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene.
  • Page 3 450 / 660 / 940 Fig. 1 min 100 min 100 min 100 Fig. 2: Minimum distance...

  • Page 4: Mounting With Wall Bracket

    Mounting with wall bracket Possibility to use guide holes for easy positioning 10 cm Align the wall bracket Fig. 3: Mounting wall bracket Fig. 4: Fastening with lockplate...

  • Page 5: Portable Use

    Mounting when a connection box is to be placed behind the unit PFS4/10/17 - 214/434/712 Fig. 5: Free space to mount the connection box behind the unit Fig. 6: Bending the wall bracket Portable use Fig. 7: Floor stand...
  • Page 6 Fig. 8: Opening the unit DISPLAY BOARD 12VDC 90°C Jumper 60/90°C 60°C RF In OUTLET SENSOR Overheat protection Fig. 9: Changing the maximum surface temperature from 90 °C to 60 °C by removing the jumper. Default 90 °C. POWER BOARD 230/400V 12VDC PFSE/D4...
  • Page 7 Accessories Type PFSS4 PFSE4 PFSS10 PFSE10 PFSE17 PFSS17 PFSE, PFSD PFSRF PFSH PFSE, PFSD PFSS PFSRF PFSH Electrical heat 230V~ PFSE Type Output Voltage Amperage Output LxHxD Weight Motor (12V) [mm] [kg] 230V~ 450x325x105 PFSE4 1000 230V~ 660x325x105 PFSE10 1750...
  • Page 8 PFSE / PFSD DISPLAY BOARD 12VDC 90°C Jumper 60/90°C 60°C RF In OUTLET SENSOR Overheat protection POWER BOARD 230/400V 12VDC PFSE/D4 INLET PFSE/D10 SENSOR PFSE/D17 PFSD PFSE...

  • Page 9: Electrical Installation

    Screw the stand to the unit with screws and toilet and bathroom facilities. included, in intended holes, PFSE4 1x, • The convector is approved for installation PFSE10/17 2x. Fig.7. in wet rooms on condition that no control devices (buttons, switches, etc.) are within...
  • Page 10 Changeover surface temperature 60 / 90 °C Overheat protection On delivery, the surface temperature is The fan convector is equipped with overheat protection. The overheat protection resets by max. 90 °C. To select the lower surface turning off the unit for 10 minutes. temperature - max 60 °...
  • Page 11 Control The fan convector has a digital display on which all settings are made and can also be remotely controlled via an app (iOS, Android) or web browser. Start-up Home screen and button unit Button unit 1 Increase / up 2 Decrease / down 3 User menu / browse / proceed 4 Return...

  • Page 12: Display Symbols

    Display symbols Fan active Fan off. Flashes Comfort mode active when cooling. Reduced mode active Fan Auto mode Frost protection mode active Active fan steps Symbol flashing Timer active Weekly program active Weekday: Symbol flashes 1 = Mon till 7 = Sun Sending/reception RF Symbol flashes.
  • Page 13 Fan modes The fan speed can be set to suit the needs, Fan mode Function modes Auto, Off, Low or High. Auto The fan runs at low speed except: • when the room temperature is more than 2 °C below the User menu set point, then the fan speed increases to high speed for a...
  • Page 14 Timer Weekly program The set temperature can be changed for a PFS has nine preset weekly program (P1 to limited time with the timer (1 hour to 45 P9) and the possibility to add four own (U1- days). The fan runs on the set value. U4).
  • Page 15 Setting weekly program Select the start time for the selected mode (Reduced/Comfort). User menu Select Confirm. Select between Reduced mode or P1 or the recently used program is shown. Comfort mode for following time. Confirm. Confirm. Select a preset program P1 - P9 Select the start time for the selected mode (Reduced/Comfort).

  • Page 16: Power Failure

    Settings Power failure Note! A power loss longer than 12 hours may require an adjustment of time and date. User menu The week program is affected if the clock is Select not correctly set. Confirm. Browse the menu options. Confirm. Menu Operation Default...

  • Page 17: Troubleshooting

    Frico for support. The text "Sens Out" The lower sensor is faulty or has beco- • Please contact Frico for support. flashes in the display me detached from its fastening. and there is no heat. The text "Sens In"...
  • Page 18 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
