Summary of Contents for Frico PF Smart

  • Page 1 Original instructions PF Smart ..28 ..49 ..9 ..19 ..38 ..60 ..71 ..81 ..92 ..103...
  • Page 2 Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene.
  • Page 3 450 / 660 / 940 Fig. 1 min 100 min 100 min 100 Fig. 2: Minimum distance...
  • Page 4: Mounting With Wall Bracket

    Mounting with wall bracket Possibility to use guide holes for easy positioning 10 cm Align the wall bracket Fig. 3: Mounting wall bracket Fig. 4: Fastening with lockplate...
  • Page 5: Portable Use

    Mounting when a connection box is to be placed behind the unit PFS4/10/17 - 214/434/712 Fig. 5: Free space to mount the connection box behind the unit Fig. 6: Bending the wall bracket Portable use Fig. 7: Floor stand...
  • Page 6 Fig. 8: Open the unit DISPLAY BOARD 12VDC 90°C Jumper 60/90°C 60°C RF In OUTLET SENSOR Overheat protection Fig. 9: Changing the maximum surface temperature from 90 °C to 60 °C by removing the jumper. Default 90 °C. POWER BOARD 230/400V 12VDC PFSE/D4...
  • Page 7 Accessories PFSS4 PFSE4 PFSS10 PFSE10 PFSS17 PFSE17 PFSE, PFSD PFSRF PFSE, PFSD PFSH PFSS PFSRF PFSH Electrical heat 230V~ PFSE Type Output Airflow Sound Voltage Amperage Output LxHxD Weight level* Motor (12V) [dB(A)] [mm] [kg] 40/60 26,5/37 230V~ 450x325x105 PFSE4 1000 60/100 28/38,5...
  • Page 8 PFSE / PFSD DISPLAY BOARD 12VDC 90°C Jumper 60/90°C 60°C RF In OUTLET SENSOR Overheat protection POWER BOARD 230/400V 12VDC PFSE/D4 INLET PFSE/D10 SENSOR PFSE/D17 PFSD PFSE...
  • Page 9 The PF Smart is suitable for most place the unit further from the wall. See Fig. 5 environments including offices and homes.
  • Page 10 Switching surface temperature 60 / 90 °C turning off the unit during 10 minutes. On delivery, max. surface temperature is set to 90 °C. To select the lower surface Replacing the fan motor temperature - max 60 °C, remove the jumper 1.
  • Page 11 Control PF Smart App • This product is considered a local space PF Smart can also be remotely controlled heater according to Ecodesign Regulation via an app (iOS, Android) or web browser. (EU) 2015/1188 and is equipped with smart...
  • Page 12: Display Symbols

    PF Smart is supplied with default settings. Default settings The temperature is easily changed by pressing Set point 21 °C + or -. PF Smart can also be adapted to Fan mode Auto individual requirements, see the following Comfort Temperature mode pages.
  • Page 13: Temperature Mode

    Fan mode The fan speed can be set to suit any Fan mode Functions requirements. Modes: Auto/Low/High/Off. Auto The fan runs at low speed except: - when the room temperature is more than 2 °C below the set point, User menu then the fan speed increases to high speed for a shorter heating Select...
  • Page 14: Week Program

    Timer Week program PFS has nine preset week programs (P1 to P9) The set temperature can be changed for a limited time with the timer (1 hour to 45 and the possibility to add four (U1-U4). days). The fan runs on the set value. The function ITCS (default) makes the control learn when it needs to start in order to reach a certain desired temperature at a...
  • Page 15 Setting week programs Select the start time for the selected mode (Reduced/Comfort). User menu Select Confirm P1 or the recently used program is shown. Select between Reduced mode or Comfort mode for following time. Confirm Confirm Selecting a preset program P1 - P9 Select the start time for the selected mode (Reduced/Comfort).
  • Page 16: Power Failure

    (OFF) with +/-. certain desired temperature at a specific Confirm with OK. time in the environment it is used. For PF Smart App. Linking the RF module See separate manual for PF Smart rF (06) to the control. App.
  • Page 17: Troubleshooting

    The function with fans off at reduced Put FRT function to OFF in Settings. mode (FRT) is active. Check the fan motor connections. The quick plug for the first motor is de- tached. If the problems continue, please contact Frico for support.
  • Page 18 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net.
