Summary of Contents for Frico Panther T Series

  • Page 1 Original instructions Panther T ..12 ..15 ..18 ..21 ..23 ..25 ..28 ..30 ..33 ..36 ..39 ..42...
  • Page 2 Panther T Panther T 13,5-15 kW (PNT135, PNT15) ø7 ø14 ø6,5 Panther T 20-30 kW (PNT20, PNT30, PNT305) ø8,5 ø15 ø9 Minimum mounting distance Wall 30° 1800 1000 Floor Ceiling FR: Distances minimales DE: Mindestabstand SE: Minimiavstånd NO: Minsteavstand DK: Minimumsafstande FI: Minimietäisyydet NL: Minimale afstand ES: Distancias mínimas...
  • Page 3 Panther T Mark and drill holes Detach bracket from the unit Mount the bracket on the wall Hang the unit on the bracket Tighten all screws Adjust the angle and fasten with screws PNT135/15: 0° - 7,5° - 15° PNT20/30/305: 0° - 7,5° - 15° - 23°...
  • Page 4 Panther T Connection PNT15 PNT135 PNT15 PNT135 400V3~ 400V3~ 500V 440V 500V 230V3~ 440V 230V3~ 500V 6.3A x 2 230V 630mA x 1 440V 500V 6.3A x 2 230V 630mA x 1 440V PNT20 PNT30 PNT20 PNT30 6.3A x 2 6.3A x 2 PNT305 PNT305...
  • Page 5 Panther T PNT305 6.3A x 2 500V 230V 440V Resetting the overheat protection FR: Réinitialisation de la protection anti-surchauffe DE: Zurücksetzen des Überhitzungsschutzes SE: Återställning överhettningsskydd NO: Tilbakestille overopphetingsvernet DK: Nulstilling af overophedningsbeskyttelsen FI: Ylikuumenemissuojan palauttaminen NL: Resetten van de oververhittingsbeveiliging ES: Reajustar la protección contra el sobrecalentamiento IT: Ripristino della protezione termica...
  • Page 6 KRT2800 165x57x60 10281 PTA01* 215x185x115 ) See www.frico.net ) See separate manual FR: L’aérotherme nécessite également un boîtier de commande PP. DE: Der Heizlüfter muss mit einem PP-Steuergerät ergänzt werden. SE: Värmefläkten måste kompletteras med manöverpanel PP. NO: Varmluftsviften må suppleres med et kontrollpanel PP.
  • Page 7 Panther T Panther T (IP44) Item Type Output Airflow Sound Sound ∆t* Motor Voltage Amperage Weight number steps power * pressure* [kW] [m³/h] [dB(A)] [dB(A)] [°C] [kg] 400V3N~* 21,7 334023 PNT15 0/7,5/15 900/1300 61 39/47 50/35 230V3~ 37,5 334024 PNT20 0/10/20 2300 400V3N~ 29,5...
  • Page 8 Panther T ) Ljudeffekt (L ), mätningar enligt ISO 27327-2: 2014, Installationstyp E. ) Ljudtryck (L ). Förutsättningar: Avstånd till aggregat 3 meter. Riktningsfaktor: 2. Ekvivalent absorptionsarea 200 m². Vid lägst/högst luftflöde (när tillämpligt). ) ∆t = temperaturhöjning på genomgående luft vid maximal värmeeffekt. Vid lägst/högst luftflöde (när tillämpligt).
  • Page 9: Internal Wiring Diagram

    Panther T Internal wiring diagram Panther T 13,5-15 kW PNT15 PNT135 400V3~ 630mA 2µF 230V3~ 230V~ 500V~ 440V~ 6,3A 6,3A 500V~/440V~ 15 16 399537 400V3N~ 230V3~...
  • Page 10 For installations not covered by ECO Design regulation (EU) 2015/1188 Panther T Note Remove the two internal fuses 6,3A in the secondary units 11 1213141516 PNT 15 / 135 Panther T 13,5-15 kW Note Remove the two internal 11 1213141516 PNT 15 / 135 Panther fuses 6,3A in the secondary units...
  • Page 11 Panther T Internal wiring diagram Panther T 20-30 kW PNT20 PNT30 PNT305 6,3A 30kW Only 6,3A 230V3~ 500V3~ 440V3~ 500V3~/440V3~ 399538 400V3N~...
  • Page 12: General Instructions

    Panther T Installation and operating instructions General Instructions The power supply to the unit must Read these instructions carefully prior to be disconnected during all service, installation and use. Keep this manual for repair and maintenance work. future reference. The product may only be used as set out in the assembly and operating instructions.
  • Page 13: Maintenance

    Panther T A 230V~ alarm signal can be obtained when not been used for a long period or stored in the overheat protection is triggered (or a damp environment, moisture can enter the temperature limiter for PNT20/30/305). element. • PNT15/135: between terminals 1 and 13 This should not be seen as a fault, but is simply rectified by connecting the appliance to •...
  • Page 14 Panther T in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. • Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
  • Page 15 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net...
