Mounting the drum module on the rack

Put the drum module up to the stop into the empty terminal of the left side arm.

Align the module and tighten the wing nut of the clamp.

Set-up and cabling

Set up the rack, the pads and the cymbals according to your needs. As a final step, all triggers need to be wired to the drum

module. Note the labelling on the drum module and the colour markings of each cable.
