Test Operation
1.12

Indoor Field Setting

Making a field setting
Field settings must be made by remote controller if optional accessories have been installed on
the indoor unit, or if the indoor unit or HRV unit's individual functions have been modified.
1.12.1 Wired Remote Controller <BRC1A51>
1. When in the normal mode, push the
2. Select the desired "mode No." with the
3. During group control and you want to set by each individual indoor unit (when mode No. 20,
4. Push the
5. Push the
6. Push the timer
7. Push the
(Example)
When setting the filter sign time to "Filter Dirtiness-High" in all group unit setting, set the Mode
No. to "10", Mode setting No. to "0" and setting position No. to "02".
126
enters the "field set mode."
21, 22, 23, 25 has been selected), push the time mode
unit No." to be set.
Note: This operation is not required when setting as a group.
button and select the first code No.
button and select the second code No.
button one time and "define" the currently set contents.
button to return to the normal mode.
button for 4 seconds or more, and operation then
button.
Test Operation R407C PLUS Series Heat Recovery System
Si33-105
button and select the "indoor
