RIGOL User’s Guide Publication Number: UGE22X00-1110 RP1018H RP1018H High Voltage Probe Sept. 2013 © 2013 RIGOL Technologies, Inc. All Rights Reserved. -
Page 2: Table Of Contents
目录 Contents 规格 ......................1 安全须知....................1 操作说明....................2 匹配电容调整 .....................2 注意事项....................3 清洁 ......................4 电压测试临界曲线 ..................4 附件 ......................5 Specification....................6 Safety Precautions ..................6 Operation ....................7 Compensation Adjustment ..............7 Warning....................8 Cleaning ....................9 Voltage Derating Curve ................9 Accessories....................10... -
Page 3: Specification
460g /80(W) x 80(H) X 320(L) mm 2. Safety Precautions Thank you for purchasing RP1018H high voltage probe. High voltage probe can prevent high voltage testers from subjecting to unexpected shocks when doing high voltage measurement work. Before using the high voltage probe, the operator must read and fully understand the safety rules. -
Page 4: Operation
Do not work alone when working with high voltage circuits. For your own safety, inspect the probes for cracks and frayed or broken leads before each use. If defects are noted, DO NOT USE the probe. Hands, shoes, floor and work bench must be dry. Avoid making measurements under humid, damp or other environmental conditions that might affect the safety of the measurement situation. -
Page 5: Warning
Adjust the frequency response of the probe to match your oscilloscope by the adjust bar attached only. Hole 2. for 200kHz Square Hole 3. Wave Adjustment for Bandwidth Adjustment Hole 1. for 200Hz Square Wave Adjustment CAUTION Please use function signal generator to output 20 Vp-p, 200 Hz square waveform. Non-professionals do not adjust the Hole 2 and Hole 3. -
Page 6: Cleaning
Do not allow any portion of the probe to submerge in the liquid. Dry the probe thoroughly before measuring voltage. Do not place the probe into the corrosive solvents or fumes as these will cause deterioration to the probe and cables. 7. Voltage Derating Curve RP1018H (18kV:3MHz / 300V:150MHz / 100V:1GHz) Frequency... - Page 7 8. Accessories Test CRT for H.V. Adjust bar Carrying Box Contact Us If you have any problem or requirement when using our products or this manual, please contact RIGOL. E-mail: service@rigol.com Websites: www.rigol.com -10-...
