This chapter contains general information and detailed specifications of the eBOX530-830-FL.
The Chapter 1 includes the following sections:


General Description

 System Specification
 Dimensions
 I/O Outlets
 Packing List
 Model List
1.1 General Description
The eBOX530-830-FL is an embedded system that supports onboard dual core
Intel® Atom™ processor N2600 (1.6GHz) processor to provide W indows 7, W indows
7 Embedded or Linux, suitable for the most endurable operation.
It features fanless design with full feature I/O, one 204 -pin unbuffered SODIMM
socket for singe channel DDR3-800/1066 MHz memory, and enhanced system
dependability by built-in W atchdog Timer.

Features
®
1. Intel NM10 chipset
Support Intel® Atom™ Processor N2600 (1.6GHz)
2.
3. Maximum to 2GB DDR3 800MHz memory
4. Ultra slim and compact design
5. Supports four USB 2.0 ports
6. Supports one RS-232/422/485 and one RS-232
7. Supports dual 10/100/1000Mbps Ethernet port
One 2.5" SATA HDD drive bay
8.
9. One front access CFast
10. Watchdog timer
11. 25W AC-DC Adapter
12. Din-rail mount (optional)
13. VESA mount (optional)
 Reliable and Stable Design
The eBOX530-830-FL adopts the advanced cooling system and supporting the CFast™,
which makes it especially suitable for vibration environments, best for industrial
automation, digital signage, energy and gaming application.
 Embedded O.S. Supported
The eBOX530-830-FL not only supports Windows 7, Windows Vista, but also supports
embedded OS, such as Windows 7 Embedded.
 Various Storage devices supported
For storage device, the eBOX530-830-FL supports one 2.5" SATA storage drive bay, and
one CFast™ slot.
Introduction
eBOX530-830-FL Series User's Manual
CHAPTER 1
Introduction
1
