Magnimage LED-570EV User Manual page 25

Output split
setting
DP output
setting
Mirror Mode
Please set the output resolution, H width and V height based on the physical
resolution of LED screen. If do not have suitable output resolution, please
select the options with bigger resolution than the reality. Or to choose the
customized output resolution, to connect with the LED screen pixel to pixel
directly.
For example, the resolution of one LED panel is 1152 × 960, the closet
resolution is "1280×1024 60Hz" , so please set the output resolution as "1280
×1024 60Hz". Furthermore, it needs to set the width as the actual width of
LED panel, which is "1152" . Likewise, set the height as the actual height of LED
panel, which is "960". And we also can define the output resolution, set the
width and height as 1152 and 960,then it can output resolution"1152×960"
directly.
Note 1: please use the bigger than 60Hz refresh rate or greater height and
width pixel output resolution judiciously, it is not sure that the back-end
equipment can support this resolution.
Note 2: customized output resolution is not the standard output signal, part
of the monitor may not be able to identify, but does not affect the LED display,
please use carefully.
23
between" the width of the current output resolution"
and "H Window"
Minimum 0, the biggest can be set to the differentials
V Position between" the height of the current output resolution"
and "V Window".
The default is off when the two outputs are not spliced;Two outputs
splicing，preset default is equal.Applies to the case of the right of the
screen is larger than the left side of the screen.By changing DVI2 / 4 H
start to reach the screen mosaic effect, the DVI2 / 4 H start is the pixel
to the left of the screen.
Divided into"iDP"and"DP loopout".
"On"or "Off"the mirror mode, default is off
