Relationship between IKE and IPsec

Figure 65 Relationship between IKE and IPsec
Figure 65
illustrates the relationship between IKE and IPsec:
•
IKE is an application layer protocol using UDP and functions as the signaling protocol of IPsec.
•
IKE negotiates SAs for IPsec and delivers negotiated parameters and generated keys to IPsec.
•
IPsec uses the SAs set up through IKE negotiation for encryption and authentication of IP
packets.
•
When IPsec SAs are traffic expired:
In FIPS mode, both the IPsec SAs and the corresponding IKE SAs are renegotiated.
In non-FIPS mode, only the IPsec SAs are renegotiated.

Protocols and standards

•
RFC 2408, Internet Security Association and Key Management Protocol (ISAKMP)
•
RFC 2409, The Internet Key Exchange (IKE)
•
RFC 2412, The OAKLEY Key Determination Protocol

FIPS compliance

Table 12
shows the support of devices for the FIPS mode that complies with NIST FIPS 140-2
requirements. Support for features, commands, and parameters might differ in FIPS mode and
non-FIPS mode. For more information about FIPS mode, see HPE FlexNetwork MSR Router Series
Comware 5 Security Configuration Guide.
Table 13 Hardware and FIPS mode compatibility matrix
Hardware
MSR900
MSR93X
MSR20-1X
MSR20
MSR30
FIPS mode
No
No
No
Yes
Yes (except the MSR30-16)
202
