2. Hardware Overview

2.1 Hardware Layout

The layout of the WGM110 Wi-Fi Expansion Kit is shown in the figure below.
WGM110 Wi-Fi
Module Radio Board
Pass-through EXP-header
Not mounted
silabs.com | Building a more connected world.
WGM110 Wi-Fi
Expansion Kit
WGM110 Wi-Fi
Module Radio Board
Wireless
Expansion Board
Mini Simplicity
connector
EXP-header for
Starter Kits
Figure 2.1. WGM110 Wi-Fi Expansion Kit Hardware Layout
UG291: WGM110 Wi-Fi® Expansion Kit User's Guide
Wireless Expansion Board
WGM110 Wi-Fi Module
Raspberry Pi connector
Not mounted
Radio Board connectors
Power switch
Hardware Overview
