- Page 1 Revival UNO DAB / DAB+ / FM RDS portable digital radio Please read this manual before use...
-
Page 2: Table Of Contents
Contents Controls ................2-3 Snooze function ..............15 Battery operation ..............3 ..............16 Using the buttons..............3 Sleep function ..............16 ...........4 ........17 Operating your radio - DAB ..........5 ..........17 Selecting a station - DAB.............6 Software version ..............18 Secondary services - DAB...........6 ...........18 Language function .............19 Finding new stations - DAB ..........6 Manual tuning - DAB ............7 Equaliser function (My EQ)..........19... -
Page 3: Controls
Controls (Top) 1. Tuning / Select / Snooze control 8. Favourite button 2. Loudspeaker 9. Mode / Alarm button 3. LCD display 10. Menu button 4. Low battery indicator 11. Auto Tune button 5. On/Off / Volume control 12. Info / Dimmer button 6. -
Page 4: Battery Operation
Controls (underneath the radio) 15. DC Input socket 16. Line Output socket 17. Battery compartment 18. Micro USB socket (inside battery compartment for service use only) Line Out 7.5V /0.8A Battery operation 15 16 1. Remove the battery cover located underneath the unit by applying pressure to the catch in the direction shown by the arrow and then lifting up the cover. - Page 5 Use only the mains adaptor provided with the product, or a genuine replacement provided by Roberts Radio. The use of alternative adaptors will invalidate the guarantee.
-
Page 6: Operating Your Radio - Dab
Operating your radio - DAB 1. Carefully extend the telescopic aerial fully. 2. Press the On/Off the radio will be in DAB mode. After each use the radio will remember the mode used and then switch on in that mode the next time it is used. -
Page 7: Selecting A Station - Dab
Selecting a station - DAB 1. Press On/Off to switch on the radio. 2. Press Mode until the 'DAB' mode is selected. 3. Rotate Tuning to step through the list of available stations. 4. Press Tuning to select and tune to the desired station. 5. -
Page 8: Manual Tuning - Dab
Manual tuning - DAB Manual tuning allows you to tune your radio to a particular DAB frequency in Band III. Any new stations found will be added to the station list. This function can also be used to assist the positioning of the aerial or the radio 1. -
Page 9: Station Order - Dab
Station order - DAB Your radio has 3 station order settings from which you can choose. The station order settings are, name, ensemble and active. Note: The default station order on your radio is name. 1. When in DAB mode, press Menu. 2. -
Page 10: Operating Your Radio - Fm
Operating your radio - FM 1. Carefully extend the telescopic aerial fully. 2. Press On/Off to switch on the radio. 3. Press Mode until the 'FM' mode is selected. 4. Rotate Tuning clockwise and then press the Auto Tune button. Your radio will scan in an upwards direction (low frequency to high frequency) few seconds the display will update. -
Page 11: Scan Sensitivity Setting - Fm
Scan sensitivity setting - FM Your radio will normally scan for FM broadcasts which are strong enough to give good reception. However, you may wish the Auto-scan function transmitters. Your radio includes a local / distant option for the Auto-scan function. -
Page 12: Display Options - Dab / Fm
Display options - DAB / FM Scrolling text (DAB and FM) Your radio has a range of display options when in DAB and FM modes:- 1. Press Info to cycle through the various options. All displays except the text display will revert to the clock display after about 10 seconds. DAB display options Your radio can display the following in DAB mode:- Signal strength (DAB only) -
Page 13: Preset Stations
Preset stations - DAB and FM To make it easier for you to tune your radio to the stations that you prefer, you may store selected radio stations as presets. Your radio holds presets separately for DAB and FM radio modes. You may set as many or as few presets as you like in each mode. - Page 14 Your radio has two alarms which can be set to wake you to DAB, FM radio or buzzer alarm. Each alarm can be set to sound once, daily, on weekdays or at weekends. In the event of a power interruption your radio has a built in memory that will retain your alarm settings. Ensure that the time is set correctly before setting the alarms.
- Page 15 9. Press Tuning 10. Rotate Tuning to choose the desired alarm minute. 11. Press Tuning 12. Rotate Tuning to choose the desired alarm day option: Daily - Will sound everyday Once - Will sound at one time only Weekdays - Will sound only on weekdays Weekends - Will sound only on weekends 13.
-
Page 16: Snooze Function
the alarm setting procedure. When your radio is set to wake by the radio alarm, your radio will switch to the selected radio station. If the radio cannot Note: If the radio is switched on because of a radio alarm you can control basic functions such as the volume control. When the alarm activates it will start softly and gradually increase in level. -
Page 17: Sleep Function
1. To disable alarms while the radio is in Standby repeatedly press the Mode/Alarm button to cycle through the alarm on-off options (see page 13, step 1). 2. Alternatively, to disable an alarm enter the alarm setup menu (see page 13, step 2-4) and rotate Tuning until the desired alarm is displayed. - Page 18 Your radio will usually set the clock time using the DAB signal. Alternatively you may set the clock manually. 1. Press On/Off to switch on the radio. 2. Press Menu. 3. Rotate and press the Tuning control to select 'TIME', 'AUTO' then choose an update option from, DAB or NO (None).
-
Page 19: Software Version
Software version The software version display cannot be altered and is just for your reference. 1. Press On/Off to switch on the radio. 2. Press Menu. 3. Rotate Tuning until 'SW VERSION' appears on the display. Press Tuning to display the software version. 4. -
Page 20: Language Function
Language function 1. Press On/Off to switch on the radio. 2. Press Menu. 3. Rotate and press the Tuning control to select 'LANGUAGE' and then select your desired language. 4. The display will change to the chosen language. 5. Press Menu as needed to exit. Equaliser function (My EQ) The sound on your radio can be adjusted to suit your personal taste for the material that you are listening to. -
Page 21: Headphone Socket
Headphone socket A 3.5mm Headphone Socket located on the top left hand corner of the radio is provided for use with either headphones or an earpiece. Inserting a plug automatically mutes the internal loudspeaker. Please be aware that the sensitivity of headphones can vary widely. We therefore recommend setting the volume to a low level before connecting headphones to the radio. - Page 22 If your radio fails to operate correctly, or some digits on the display are missing or incomplete carry out the following procedure. 1. Press On/Off to switch on the radio. 2. Press Menu. 3. Rotate Tuning until 'RESET' appears on the display. Press Tuning. 4.
-
Page 23: Safety Notices
Safety notices • Your radio and AC/DC adaptor should not be exposed to dripping or placed on the radio or adaptor. Do not allow this radio to be exposed to water, steam or sand. Do not • It is recommended to operate the product such that there is a minimum leave your radio where excessive heat could cause damage such as in distance (10cm recommended) to adjacent objects in order to ensure a parked car where the heat from the sun can build up even though the... - Page 24 Any claim under this guarantee should be made through the dealer from whom the product was purchased. It is likely that your Roberts dealer will be for attention. In the event that it is not possible to return the product to the Roberts dealer from whom it was purchased, please contact Roberts Radio using the contact details on the www.robertsradio.com website.
