Stream 95i User Guide
The Stream 95i represents a groundbreaking portable smart speaker with
powerful 2:1 stereo sound. It seamlessly combines the charm of traditional radio
with the innovation of streaming technology, as well as integrating Alexa for
added convenience and functionality.
As this device links to WiFi, please perform an over the air update when first
setting up to make sure that you have the latest firmware.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stream 95i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roberts Stream 95i

Summary of Contents for Roberts Stream 95i

  • Page 1 Stream 95i User Guide The Stream 95i represents a groundbreaking portable smart speaker with powerful 2:1 stereo sound. It seamlessly combines the charm of traditional radio with the innovation of streaming technology, as well as integrating Alexa for added convenience and functionality.

  • Page 2: Key Features

    Alexa voice assistant with physical mute switch for privacy • Chromecast built-in to stream favourite music and apps from smartphone/tablet • Full control via the Roberts Radio app from Apple iOS and Android devices • Multiroom streaming capable (with other Icon/Stream95i or Linkplay based products, for example: WiiM) •...

  • Page 3: Use Cases

    • Set a sleep timer to turn off the radio after a set period • Change EQ settings • Change playback modes Use the Roberts App to: • Play audio from your favourite streaming service on your device • Select an internet radio station to play on your device •...

  • Page 4: Product Controls

    Product Controls...

  • Page 5: Product Usage

    Plug the other end of the power cable into a power outlet. Press the Power/ Volume dial to turn on the unit. When the Stream 95i is turned on, the LED array will blink from left to right to indicate that it is turning on. This will take approximately 20 seconds.

  • Page 6: Select Audio Source

    Your audio system may be configured using the display and buttons on the audio system. However, to take advantage of all of the audio systems advantages, it should be configured using the Roberts Radio app and can be voice controlled using Alexa.

  • Page 7: Dab Radio

    DAB Radio 1. Make sure that the aerial is fully extended and the unit is in a location that can receive a strong FM/DAB signal. 2. Press the MODE button 3. Turn the Tuning dial and push to choose DAB. The first use will cause the system to scan for available radio stations.
  • Page 8 FM Radio 1. Make sure that the aerial is fully extended and the unit is in a location that can receive a strong FM/DAB signal. 2. Press the MODE button 3. Turn the Tuning dial and push to choose FM. 4.
  • Page 9 Favourites Save Preset To save a radio station in DAB or FM mode, start listening to the station you want to save, then: 1. Long press the FAVOURITE button. The system displays a list of ‘slots’ to save the station to. 2.

  • Page 10: Connect To Bluetooth

    4. On your smart device, enter Bluetooth settings and look for ‘Stream95i Forte ----’ (where ---- is a unique code for your device, or the name that you have renamed your device through the Roberts Radio app). Choose this device and your phone should pair and connect. Whilst paired, you can stream from any audio app on your phone to the device.

  • Page 11: Usb Playback

    USB Playback You can plug in a USB memory device in to the USB socket to play back compatible media files. The USB stick should be formatted on a PC (Fat 32). Check online for details of compatible media formats - mp3 is the most commonly used for this purpose.

  • Page 12: Aux Input

    AUX Input The base panel features a 3.5mm stereo aux input. Use this to connect the device as a speaker to external equipment such as a CD player or TV. Press MODE and choose AUX to listen to audio being played to this device. USB Charging The socket can also be used to charge your phone at up to 10W.
  • Page 13 first setting up to make sure that it has the latest firmware. You must first download the Roberts Radio app from Google Play or iOS App Store. The Roberts Radio app allows you to configure many things on the Stream 95i in a convenient way on your phone or tablet.
  • Page 14 3. Press and hold the ACTION button until the 4 indicators are blinking amber on the device and WiFi setup starts. 4. Open the Roberts Radio app on your phone and choose the ‘+’ button to add a device to your WiFi network. When the device is connected, it will check for, and download the latest firmware.

  • Page 15: Browse Tab

    Browse Tab Within the Browse tab you can discover the music and content you want to stream to your device. Search Use the search bar to explore your personal library. Preset Preset Content allows you to save your favourite internet radio stations, podcasts and playlists.
  • Page 16 For example, when using Spotify on your phone, look for the ‘speakers’ icon within the Spotify app and choose the Stream 95i to play audio. Spotify is an extremely convenient way to play audio, as the Stream 95i will stream audio directly from the Internet without draining your phone’s...
  • Page 17 Now Playing View the audio currently being played through the app selecting on the Now Playing page. From this screen, you can: 1. Check the audio source at the top centre of the screen 2. Play/Pause and skip forward/ back the audio stream 3.
  • Page 18 Save Preset (app) To save a preset through the app: 1. Select a music service and stream content to listen to. 2. Select the Now Playing bar.
  • Page 19 3. On the Now Playing Screen, click on the 3 dots. 4. Press on the Preset option. The number of options available when selecting the 3 dots will depend upon the music service. 5. Select one of the available presets from the list.
  • Page 20 Recall Preset (app and on device) To quickly recall a preset that has been saved via the app, there are 2 options: 1. On the device, short press the FAVOURITE button, then choose one of the presets from the displayed list. The system will recall the station/ playlist/ folder/ podcast.
  • Page 21 My library My library refers to music that you own on your phone/tablet/pc/home server/USB. To save a song as a favourite or add to a playlist: 1. Select My Music from the Browse tab 2. Choose a source, for example your phone music library. From this screen, it is also possible to select My Playlists to either create or delete playlists.
  • Page 22 3. Select a song from your library list. Then click on the now playing bar and from here click on the 3 dots. 4. Choose to add the song to either your favourites on the app and/or add to a playlist.

  • Page 23: Device Tab

    Device Tab View all your devices and manage volume and grouping settings. Grouping Devices Synchronize and play music in a group if you have multiple streaming capable devices (e.g. Stream95i, Revival Icon, or Linkplay based products) connected to your WiFi. 1.

  • Page 24: Settings Tab

    5. Amazon Alexa Settings 6. Chromecast Audio – Your device is enabled to stream music directly from hundreds of Chromecast-enabled apps to Stream 95i in the bit perfect fashion. You can disable this here if you wish. 7. EQ – You may want to change the sound profile of the device. Choose from a custom User EQ or select from 6 preset EQ settings.

  • Page 25: Amazon Alexa

    “Alexa, volume up”. Setting up Amazon Alexa To use the Alexa voice assistant, you need to enter the settings page within the Roberts Radio app. 1. Select the BROWSE tab and in the Music services list select Amazon Alexa.

  • Page 26: Useful Features

    You can disable the microphone by sliding the MICROPHONE MUTE slider to the right on the device. The device is not listening and can no longer hear your voice commands. However, you can press the ACTION button on the Stream 95i and say your commands. For example, Press ACTION button and then say “Play BBC radio 4”.
  • Page 27 Google Chromecast. 1. Login to your Google account in the Google Home app. 2. Then, you need to open the Roberts Radio app, find the Stream 95i in the Device tab. 3. Select the configuration icon of the device.
  • Page 28 4. Then browse Chromecast audio from the settings menu of the app. 5. Tap Enable on your app to make the Google Chromecast function available. 6. Next, you need to open your media player app, e.g. Spotify. 7. In the Spotify app, you can browse the device list, then select either to use Spotify Connect or Google Cast as the streaming service.

  • Page 29: Energy Mode

    Energy Mode Your device has 2 energy modes, Normal and Green. In Normal mode the Stream 95i will go to standby mode after 15 minutes if there is no audio, user interaction or network request. Any user interaction on the device, voice control (if the slider switch is not in privacy mode), or network request will turn the device on.

  • Page 30: Factory Reset

    If you wish to set up the WiFi, this may be initiated here by selecting Yes to proceed. Factory Reset If you wish to completely reset your Stream 95i to its initial state, this may be performed here. Select Yes to proceed with factory reset. System Version The software version display cannot be altered and is just for your reference.

  • Page 31: Battery (Not Included)

    Battery (not included) You can power the Stream 95i from the Roberts BP3 battery, which can be bought from www.robertsradio.com. The battery will enable the Stream 95i to play for up to 7 hours with its 3200mAh capacity, transforming it into a portable product.

  • Page 32: Safety And Warranty Information

    Use only the mains adaptor / mains cable provided with the product, or a genuine replacement provided by Roberts Radio. The use of alternative adaptors / mains cables will invalidate the guarantee.

  • Page 33: Electro-Magnetic Compatibility Advice

    Headphones IMPORTANT: Excessive sound pressure from earphones and headphones can cause hearing loss. To prevent possible hearing damage, do not listen at high volume levels for long periods. For products with WiFi Use restriction: This device is authorized in the following countries for indoor use only when used with 5GHz Wi-Fi (5150 to 5350MHz;...

  • Page 34: Product Markings

    Product Markings This symbol indicates AC voltage. This symbol indicates Class II equipment. For indoor use only. Polarity of d.c. power connector. This symbol indicates energy efficiency marking. This symbol indicates DC voltage. Battery Safety (General) IMPORTANT: The batteries (battery pack or installed batteries) should not be exposed to excessive heat such as from direct sunshine, fire or the like.
  • Page 35 Hereby, Roberts Radio, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

  • Page 36: Warranty

    In the event that it is not possible to return the product to the Roberts dealer from whom it was purchased, please contact Roberts Radio using the contact details on the www.robertsradio.com...

This manual is also suitable for:

5038301311209Revival icon
