Page 1: Operating Instructions
TC60 | TC63-30 Touch probe Workpiece measurement Radio transmission Multidirectional Wear-free measuring mechanism Modular system Batch- & mass production Contour measurement Axes compensation – Operating instructions English Type P03.6000-010 | P03.6300-010 focus on productivity... -
Page 3: Table Of Contents
Content 1. Safety Rules ..........4 2. System Overview ..........5 2.1 Display Elements....................5 2.2 Tool Holder ......................7 2.3 Technical Data ..................... 8 2.4 Complete System....................9 3. Mounting and Commissioning ........10 3.1 Batterie einsetzen / wechseln ................10 3.2 Mounting of the Tool Holder ................ -
Page 4: Safety Rules
Safety Rules Zeichenerklärung: CAUTION Important advice for appliance protection Advice to secondary literature Additional advice LED shines LED flashes Green Blue Orange Violet Abbreviations: BTH Blum Tool Holder Tightening Torque Low Force 1. Safety Rules Important advice for appliance protection: •... -
Page 5: System Overview
System Overview 2. System Overview 2.1 Description Shaft for tool holder BTH Centering screws Battery cover Battery Hall sensor MODE Hall sensor SET LED Status 3 pcs. Measuring mechanism Stylus (10) Pin hole Fig. 2.1 2.2 Display Elements Colour LED Status (7) Standby Stylus initial position GN GN GN GN... - Page 6 System Overview TC60 TC63-30 Ø63 Ø63 Ø28 Ø28 TC63-30 TC76-T Ø25 Fig. 2.3 Stylus length Max. deflection X/Y (mm) (mm) TC60 TC63-30/ TC76 Tab. 2.1 © by Blum-Novotest 2010...
-
Page 7: Tool Holder
System Overview 2.3 Tool Holder Type Order number System BTH 50(TC60/63-30) HSK-A 40 P03.8000-035.140A HSK-A 50 P03.8000-035.150A HSK-A 63 P03.8000-035.163A HSK-A 80 P03.8000-035.180A HSK-A 100 P03.8000-035.100A HSK-E 40 P03.8000-035.140E HSK-E 50 P03.8000-035.150E HSK-E 63 P03.8000-035.163E SK 30 P03.8000-035.230 SK 40 P03.8000-035.240... -
Page 8: Technical Data
System Overview 2.4 Technical Data TC60 TC63-30 / TC76-T Approach direction ± X, ±Y, -Z ± X, ±Y, ±Z Measuring force XY-direction 2 N** 1,3 N*** 5,9 N Measuring force Z-direction Max. deflection XY ± 15° ± 15° Max. deflection Z... -
Page 9: Complete System
System Overview 2.5 Complete System TC60 TC63-30 RC66 Z-Nano IF59 - A2 Fig. 2.4 RC66: ⇒ switch ON/OFF via radio signal ⇒ signal transmission for TC series Installation instructions RC66 (P03.6600-000.011) Installation instructions IF59-A2 (P03.5900-000.011) © by Blum-Novotest 2010... -
Page 10: Mounting And Commissioning
Mounting and Commissioning 3. Mounting and Commissioning 3.1 Batterie einsetzen / wechseln Empfohlener Batterietyp: Type Ultralife Lithium U9VL-J 1200 Contin. ca. xxx h operation 5% Use ca. xxx Tage Standby ca. xxx Tage Order number 980702003 Dispose batteries acc. to legal requirements. CAUTION Risk of short-circuit Be careful to correct position of gasket. -
Page 11: Mounting Of The Tool Holder
(4 internal hexagon screws 2 mm) - M < 2 Nm Run-Out: < 10 m 8. Tighten holding screw (M = 12 Nm) 9. Carry out calibration cycle TC60/TC63-30: 2 mm < 2 Nm Fig. 3.2 © by Blum-Novotest 2010... -
Page 12: Mounting Of The Tc76-T
Mounting and Commissioning 3.3 Mounting of the TC76-T = 10 Nm Fig. 3.3 hook wrench (scope of delivery) Mounting of the extension / angle: see referring data sheet © by Blum-Novotest 2010... -
Page 13: Mounting Of The Stylus
3.4 Mounting of the Stylus CAUTION Damage of the measuring mechanism • TC60: When mounting the stylus into the probe, it is absolutely necessary to lock the probe with the mounting tool B to avoid torsion of the measuring mechanism. •... -
Page 14: Cranked Styli (Tc63-30/Tc76)
Mounting and Commissioning 3.5 Cranked Styli (TC63-30/TC76) CAUTION Damage of the measuring mechanism Pay attention to area of operation and max. overtravel Fig. 3.5 Fig. 3.6 Fig. 3.7 Fig. 3.8 © by Blum-Novotest 2010... -
Page 15: Display Basic Adjustments
Mounting and Commissioning 3.6 Display Basic Adjustments 3. Automatic display of the 1. Remove battery 2. Insert battery basic adjustments: First colour: MODE Wait 30 Second colour: sec. MODE Transmission mode Normal* Robust (3x MODE – SET) Fast Switch-on time Fast Normal* (3x MODE –... -
Page 16: Programming Of The Basic Adjustments
Mounting and Commissioning 3.7 Programming of the Basic Adjustments In this mode the basic adjustments can be set. 1. Remove Battery 2. Insert Battery 3. Activate programming mode (Polarity!) during display phase (MODE): wait 30 sec. 4. Change adjustments (SET) 5. - Page 17 Mounting and Commissioning Activate programming sequence: MODE • standard adjustment Transmission Normal Mode • ambient conditions with Robust radio interferences • high chip pollution • fast measuring speeds Fast • interference-free ambient conditions • Fast fast switch-on time Switch-on • setting decreases battery life time •...
-
Page 18: Probe Pairing
Maintenance 3.8 Probe Pairing Installation instructions IF59-A2 (P03.5900-000.011) 3.9 Switch-on Probe (via radio receiver) Optical by e.g. M-Code Installation instructions RC66 (P03.6600-000.011) Installation instructions IF59-A2 (P03.5900-000.011) 4. Maintenance • probe needs minimum maintenance only • Keep the glass ring clean •... -
Page 19: Exchange Of External Bellows
Maintenance 4.2 Exchange of External Bellows It is not allowed to exchange the internal bellows! CAUTION In case that it should be damaged, please send probe for repair. Damage of the measuring system The measuring system is not allowed to be twisted! TC76-LF (low force): The bellows is allowed to be exchanged by Blum-Novotest only! - Page 20 Maintenance Fig. 4.1 TC60 Fig. 4.2 TC63-30 / TC76 (10) Measuring mechanism (14) Centering ring (10a Groove (15) Internal bellows (13) External bellows (16) Front ring © by Blum-Novotest 2010...
-
Page 21: Trouble Shooting
Probe is outside Check transmission range between RC66 of the and TC60 transmission Check adjustment of transmission power range (TC60 and IF59-A2) No pairing of the Check pairing probe on IF59-A2 LED Status flashes Probe is outside Check transmission range between... -
Page 22: Order Numbers
Spare and wear parts Spare and wear parts are not subject to warranty. Bellows for TC60 P03.8000-020.002 Bellows for TC76 P03.8000-020.010 Battery for Probe TC60 / 63-30 980702003 Type Ultralife Lithium U9VL-J-9V 1200mAh Accessory set for TC60 P03.8000-020.001 Accessory set for TC63-30 P03.8000-020.013... - Page 23 Order Numbers Styli for probe TC60 Ceramic Length Ø 50 mm 2 mm P03.8000-010.050.02 4 mm P03.8000-010.050.04 5 mm P03.8000-010.050.05 6 mm P03.8000-010.050.06 75 mm 6 mm P03.8000-010.075.06 100mm 2 mm P03.8000-010.100.02 3 mm P03.8000-010.100.03 4 mm P03.8000-010.100.04 5 mm P03.8000-010.100.05...
- Page 24 Order Numbers Styli for probe TC76 Ceramic Length Ø 50mm 2 mm P03.8000-020.050.02 4 mm P03.8000-020.050.04 5 mm P03.8000-020.050.05 75 mm 5 mm P03.8000-020.075.05 100 mm 5 mm P03.8000-020.100.05 Carbide Length Ø 30 mm 2 mm P03.8000-022.030.02 3 mm P03.8000-022.030.03 4 mm P03.8000-022.030.04 5 mm...
-
Page 25: Shipping Instructions / Storage
Shipping Instructions / Storage 7. Shipping Instructions / Storage • If the probe should be stored for a longer period, please remove the battery from the battery box. • If you return the probe for repair, please enclose a detailed error description and the probe certificate. -
Page 26: Radio Approval
Radio Approval 8. Radio Approval Area: Radio Approval: Regulations: Europe: 0681 EN 300 328 V1.4.1, EN 301 489-17 V1.2.1, EN 60950-1:2001 Japan: 202WW10568411 “This device has been granted a designation number by Ministry of Internal Affairs and Communications under „Ordinance concerning Technical Regulations Conformity Certification etc. -
Page 27: By Blum-Novotest
EC Declaration of Incorporation acc. to the EC Machine Regulations 2006/42/EC in the edition from 17 May.2006 We hereby confirm that the subsequently following components are defined for the installation into other machines and that they are in accordance with the following safety requirements of the EC regulations. - Page 28 Service Order Please fill out completely this repair order and attach it to the system. This will save you and us costs due to time-consuming inquiries and ensures a quick repair. Blum-Novotest GmbH Kaufstr. 14, 88287 Gruenkraut/Gullen - Germany Tel. +49 751 6008-0, Fax. +49 751 6008-156 Company: Department: Contact:...
- Page 29 focus on productivity Blum-Novotest GmbH Kaufstr. 14 88287 Gruenkraut, Germany Tel.:+49 751 6008-0 Fax:+49 751 6008-156 www.blum-novotest.com vk@blum-novotest.com Support Hotline: Vertrieb/sales: Tel.:+49 751 6008-200 Service LaserControl : Tel.:+49 751 6008-202 Service Messtaster/probes: Tel.:+49 751 6008-203 Blum-Novotest GmbH Prüftechnik KK Blum Laser Measuring Technology Willich, Germany Nagoya, Japan Tel.
