- Page 1 Touch probe Workpiece Measurement Infrared Transmission shark360 Technology Wear‐Free Measuring Sys‐ Single & Mass Production Axes Compensation Operating instructions English Type TC50 | TC51 | TC52 TC53‐10 | TC53‐30 | TC54‐10...
- Page 2 Copyright Passing on as well as duplication of this documentation, evaluation and communication of its content are prohibited without specific authorization. Contraventions are subject to damages. All rights reserved. The language version of the manufacturer (DE/EN) is decisive for the technical content. Subject to technical change without notice. Original operating instructions © 2003 ‐ 2018 by Blum‐Novotest GmbH All brands stated in this document are the property of the respective brand owners. Article number of this documentation: 180225_EN...
-
Page 3: Table Of Contents
5. Notes concerning measuring sequence. . . . . . . . . . . . . . . . . . . . . . . . 28 6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 6.1 Cleaning of the transparent ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 6.2 Exchange of the external bellows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 8. Order numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 9. Shipping instructions / storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 10. EC Declaration of Incorporation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 11. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 © by Blum‐Novotest V2A | 04/2018... -
Page 4: Introduction
Introduction 1. Introduction Please read and observe the notes included in these instructions. Subject to technical change without any notice. Keys CAUTION! signifies a danger, which may cause injuries, if it is not avoided. NOTICE signifies measures to avoid material damages. Advice for secondary literature Additional advice Don’t use compressed air for this step. The CE‐label confirms, that the product as described complies with the product‐spe‐ cific European regulations. Green Blue Orange Violet White LED shines LED flashes BTH Blum tool holder Low Force tightening torque V2A | 04/2018 © by Blum‐Novotest... -
Page 5: Safety
Safety 2. Safety CAUTION! Damage of the measuring system due to operating error is possible. Handle the measuring system like a precision tool. Keep the measuring system clean. Mount the measuring system in assigned tool holders only. Limit the measuring block over travel by programming, see chapter 5.. Read and observe all notes of the machine tool manufacturer. Do not disable safety inter‐ lockings. NOTICE Damage of the measuring system by a short circuit is possible Aggressive liquids may destroy seals. Do not operate the measuring system in a working environment with aggressive coolants! Coolants must not contain aggressive contents, that can damage plastics or rubber parts (e.g.: acetone, alcohol, ethanol, methanol, cleaning benzine, solvents, ...). Coolants may not exceed a ph‐level of 9.5. Please contact us if you have any questions! We also have solutions for special applications. © by Blum‐Novotest V2A | 04/2018... -
Page 6: System Overview
Modular System ● ● ● ● ● ● Wear‐free Measuring Mechanism ● ● ● ● ● ● Single & Mass Production ● ● ● ● Pulling Measurement ● ● ● ● ● ● Axes Compensation ● ● Contour Measurement ● Tool Length Measurement ● Tool Radius Measurement ● Tool Breakage Detection V2A | 04/2018 © by Blum‐Novotest... -
Page 7: Description
System overview Description (1) Tool holder BTH (7) LED Status (3 x 120° = 360°) (2) Centring screws (8) Transmitter diode TC50/51/53‐30: 6x60° = 360° (12x) (3) Battery compartment TC52/53‐10/54‐10: 6x60° = 360° (4) Colour coding (9) Receiver diode (5) Battery 3x120° = 360° (6a) Hall sensor MODE (12) Stylus (6b) Hall sensor SET Display elements Colour LED (7) Standby Stylus initial position Stylus deflected Stylus initial position ‐ battery low Stylus deflected ‐ battery low Battery empty Tab. 3‐1 © by Blum‐Novotest... -
Page 8: Dimensions
System overview Dimensions TC50 TC51 TC53-30 Ø63 Ø63 Ø63 Ø28 Ø28 Ø28 TC53-30 70° 70° 70° 50° 50° 50° TC76-T Ø24,9 TC52 TC53-10 TC54-10 Ø40 Ø40 Ø40 Ø13 Ø13 Ø13 TC53-10 60° 60° 60° TC76-T Ø24,9 6 (TC52) 3,5(TC52 T) Fig. 3‐1 ... -
Page 9: Technical Data
System overview Technical data TC50 TC51 TC53‐30/ TC76‐T Approach direction ± X, ± Y, ‐Z , ‐Z, +Z ± X, ± Y, ±Z Measuring force • direction X/Y: see Tab. 3‐5 ... Tab. 3‐7 Measuring force • direction Z: 7.0 N 4.0 N 5.9 N 2.0 N Max. deflection • direction X/Y (see Tab. 3‐4): ± 15° 15° ± 15° • direction Z: 10 mm ‐Z: 6 mm 5 mm +Z: 3 mm... - Page 10 225 g 230 g (TC53‐10) Protection class IP68 Signal transmission Infrared Transmitter range ±60° in Z, 360° in X/Y Battery (2 pieces) Saft Lithium LS14250 (½ AA, 3.6 V) 1200 mAh Tool holder HSK‐SK‐BT BTH 25 Storage temperature ‐20 °C ... +70 °C Operating temperature +5 °C ... +50 °C see chapter 4.5 with accessories (e.g. extension, angle): max. acceleration 10 m/s Stylus L=30 mm Tab. 3‐3 V2A | 04/2018 © by Blum‐Novotest...
- Page 11 System overview Max. deflection X/Y [mm] Stylus length [mm] TC50 TC51 TC52 TC52 T TC53‐10/TC76 TC52 LF TC53‐30/TC76 TC54‐10 TC54‐10 T Tab. 3‐4 Max. deflection X/Y Measuring force X/Y [N] Stylus length [mm] TC50 TC51 TC52 TC53‐10/TC76 TC53‐30/TC76 TC54‐10 Tab. 3‐5 Measuring force X/Y Measuring force X/Y ‐ T [N] Stylus length [mm] TC52 T TC53‐10/TC76‐TT TC53‐30/TC76‐TT TC54‐10 T 1.15 Tab. 3‐6 Measuring force X/Y ‐ T (robust design for lathes applications) © by Blum‐Novotest V2A | 04/2018...
-
Page 12: Complete System
System overview Measuring force X/Y ‐ LF [N] Stylus length [mm] TC52 LF TC53‐10/TC76‐LF TC53‐30/TC76‐LF TC54‐10 LF 0.65 0.44 0.31 0.24 0.17 Tab. 3‐7 Measuring force X/Y ‐ LF (Low Force) Complete system Fig. 3‐2 IC56 / IC57: • Switch ON/OFF via IR flash • Signal transmission for TC series • Touch probe TC and tool setting probe IR can alternatively be programmed to TC or DUO. Installation instructions IC56 Installation instructions IF59 V2A | 04/2018 © by Blum‐Novotest... -
Page 13: Mounting And Commissioning
Mounting and commissioning 4. Mounting and commissioning NOTICE Damages caused by improper installation/dismounting Use original replacement parts only as well as the provided special tools. Pay attention to the correct orientation of the interlocking disk (inscription pointing to the stylus). Consider the maximum tightening torque. Insert / change battery TC50, TC51, TC53‐30 Recommended battery Type: Type Saft Lithium LS14500 (AA, 3.6 V) 2600 Contin. operation approx. 254 h 5% Use approx. 207 days Standby approx. 2 years Order number 170407 Tab. 4‐1 Further recommendations: Type AA 3.6 V Xeno XL‐060F 2400 Vitzrocell SB‐AA11 2500 Tadiran SL‐360 2400 Tab. 4‐2 TC52, TC53‐10, TC54‐10 Recommended battery Type: Type Saft Lithium LS14250 (½... - Page 14 Mounting and commissioning Further recommendations: Type ½ AA, 3.6 V Tadiran TL‐4902 1200 Xeno XL‐050F 1200 OmniCell ER‐14250 1200 Vitzrocell SB‐AA02 1200 Tab. 4‐4 Dispose batteries according to legal regulations. NOTICE Damage to the measuring system by faulty operation possible. Check the correct position of the gasket inside the battery compartment. Keep the battery compartment absolutely clean and dry. Slightly grease sealing face of the lid before inserting it. Fig. 4‐1 (5) Battery (10) Gasket (11) Battery compartment lid V2A | 04/2018 © by Blum‐Novotest...
- Page 15 Mounting and commissioning 1. Clean the measuring system carefully. 2. Untighten the screws at the battery compartment lid. 3. Pull back both screws and remove the battery compartment lid. 4. Remove the batteries. 5. Clean and dry the battery compartment carefully with absorbent paper. 6. Put in new batteries. Please consider the polarity of the batteries. 7. Please control if the gasket is inserted professionally: small, evenly space between sealing lip and wall 8. Put in the battery compartment lid precisely and mount it (M = 0.7 Nm). Thereby, please check the O‐rings and grease it, if necessary. 9. Basic adjustments are displayed automatically, see chapter 4.6. © by Blum‐Novotest V2A | 04/2018...
-
Page 16: Mounting Of The Tool Holder
Mounting and commissioning Mounting of the tool holder NOTICE Destruction of the measuring system by rotation possible. The measuring system should not be twisted when mounting the tool holder. The clamping screw (A) must be aligned with the centring screws. NOTICE Damage to the spindle by coolant possible. Please use the coolant pipe for HSK tool holders for machine tools with internal coolant sup‐ ply. F < 0,25 N 360° Fig. 4‐2 (2) Centring screws (B) Allen key BTH 50: 6.0 mm, M < 20 Nm (A) Clamping screw BTH 25: 3.0 mm, M < 4 Nm (C) Allen key BTH 50: 2.0 mm, M < 2 Nm BTH 25: 1.5 mm, M < 2 Nm V2A | 04/2018 © by Blum‐Novotest... - Page 17 Mounting and commissioning 1. Insert the measuring system into the tool holder (system BTH). 2. Tighten the clamping screw just slightly. Adjustment of the run‐out at TC51 with optical presetter! 3. Insert the probe into the spindle (TC50, TC52, TC53‐10, TC53‐30, TC54‐10 only). 4. Set the dial gauge on the stylus. 5. Rotate the probe by 360°. 6. Adjust the concentricity (4 hexagon socket screws 2 mm): e.g. X‐direction: Release the centring screws (2a) and (2c) just slightly. Adjust the concentricity by alternate release and tightening of the centring screws (2a) and (2c). Y‐direction: Release the centring screws (2b) and (2d) just slightly. Adjust the concentricity by alternate release and tightening of the centring screws (2a) and (2c). Concentricity deviation: TC50, TC52, TC53‐10, TC53‐30, TC54‐10: < 10 µm TC51: < 100 µm All centring screws are tightened. 7. Tighten the clamping screw. The concentricity adjustment is now fixed. 8. Check the concentricity. 9. Carry out a calibration cycle. © by Blum‐Novotest V2A | 04/2018...
-
Page 18: Mounting Of The Tc76-T
Mounting and commissioning Mounting of the TC76‐T Fig. 4‐3 (H) Hook wrench = 10 Nm Mounting of the extension / angle: see referring data sheet V2A | 04/2018 © by Blum‐Novotest... -
Page 19: Mounting / Changing Of The Stylus
Mounting and commissioning Mounting / changing of the stylus TC50, TC51, TC52: NOTICE Damage to the measuring system by improper mounting possible. The measuring element may not be deflected during mounting. When mounting please always use the provided tools. TC53‐10, TC53‐30, TC54‐10: NOTICE Damage to the measuring system by improper mounting possible. The measuring element may not be deflected during mounting. When mounting please always use the interlocking disk. The interlocking disk must fit backlash free. Please ensure the correct orientation of the interlocking disk (inscription facing upwards). Remove the interlocking disk before measurement. Damaged parts are not reusable! Calibrate the measuring system after mounting by the calibration cycle. © by Blum‐Novotest V2A | 04/2018... - Page 20 Mounting and commissioning Fig. 4‐4 TC50 | TC51 | TC52 | TC53‐10 | TC54‐10 (C) Allen key 1.5 mm (E) Mounting tool = 1 Nm (D) Interlocking disk Fig. 4‐5 TC51 (18) DIN EN ISO 4026 M3 x 3 (DIN 913) ~ 0.5 Nm V2A | 04/2018 © by Blum‐Novotest...
-
Page 21: Cranked Styli
Mounting and commissioning Cranked styli NOTICE Damage of the measuring system due to misuse is possible. Pay attention to the area of operation and the maximum overtravel. Z+ measurement: max. overtravel [mm] 15 20 25 30 35 40 45 50 55 60 65 P [mm] Overtravel Z+ measurement: area of operation C measurement: area of operation [mm] [mm] 16,5 P [mm] P [mm] Fig. 4‐6 © by Blum‐Novotest V2A | 04/2018... -
Page 22: Display Of The Basic Adjustments
Mounting and commissioning Display of the basic adjustments The measuring system can be configurated for different applications. After the batteries have been inserted, the display of the basic adjustments is started. The magnetic pin is not required. 1. Remove the batteries. 2. Insert the batteries after 30 sec. Observe the polarity of the batteries. Insert the battery compartment lid. The LED status (7) starts to flash. The basic adjustments are displayed (display phase). 3. After completing the display the measuring system goes into standby. MODE SET 30 sec. MODE Fig. 4‐7 (7) LED Status If the LED Status (7) is flashing or shining red, please check the batteries, see chapter 7. The basic adjustments can be specified on order. V2A | 04/2018 © by Blum‐Novotest... - Page 23 Mounting and commissioning MODE System IC55 (3 x MODE ‐ SET) IC56 IC56‐BLUM Reserved Transmission mode (3 x MODE ‐ SET) Option R Reserved Switch‐off optical off (Flash) (3 x MODE ‐ SET) 12 sec. timeout off 33 sec. timeout off 134 sec. timeout off Transmission power 50 % (3 x MODE ‐ SET) 100 % 200 % Battery O.K. (3 x MODE ‐ SET) Standby Standard IC56/IC57 ‐ IF59 © by Blum‐Novotest V2A | 04/2018...
-
Page 24: Programming Of The Basic Adjustments
Programming of the basic adjustments In this mode the basic adjustments can be changed. The position of the elements on the transparent ring may differ, see chapter 3.2. Magnetic pin 1. Remove the batteries. 2. Reinsert the batteries after 30 sec. Please pay attention to the polarity of the batteries. In‐ sert the battery compartment lid. The LED Status (7) starts flashing. The basic adjustments are displayed (display phase). 3. Switch to the programming mode during the display phase: Hold the magnetic pin on MODE, until the LED status changes from green to violet. MODE SET 30 sec. 5 sec. MODE MODE MODE 4. Change adjustments (SET): Hold the magnetic pin on label SET. 5. Menu change (MODE): Hold the magnetic pin on label MODE. The LED Status flashes briefly, confirming the menu change. MODE (7) LED Status 6. After the last menu, the basic adjustments will be repeated (3 x MODE ‐ SET). During the display phase, it can be changed back into the programming mode. V2A | 04/2018 © by Blum‐Novotest... - Page 25 Mounting and commissioning MODE System IC55 IC56 MODE IC56‐BLUM Reserved Transmission mode Option R MODE Reserved Switch‐off optical off (Flash) 12 sec. timeout off MODE 33 sec. timeout off 134 sec. timeout off Transmission power 50 % 100 % MODE 200 % Automatic display of the basic adjustments Standby Setting for all measuring cycles with no automatic error analysis (OEM cycles) Increased safety of data transmission due to redundancy Setting for Blum measuring cycles (automated repetition measurement due to error handling) Condition: Signal Error connected to IF59 (X1) © by Blum‐Novotest V2A | 04/2018...
-
Page 26: System Coding
IC56 - TC mode DUO no reception IC56 - DUO Mode interference reception o.k. incorrect system send flash initial position probe deflected Probe 1: battery o.k. Probe 2: battery low www.blum-novotest.com IC56-TC IC56-DUO Blum-Novotest Art.Nr.988350040 Fig. 4‐8 V2A | 04/2018 © by Blum‐Novotest... -
Page 27: Switch-On Probe (Via Receiver)
Mounting and commissioning Switch‐on probe (via receiver) • Optical by e.g. M‐Code • Optical by autoflash mode Every second the receiver sends a signal (Flash), no control signal is needed. Installation instructions IC56 Installation instructions IF59 © by Blum‐Novotest V2A | 04/2018... -
Page 28: Notes Concerning Measuring Sequence
Notes concerning measuring sequence 5. Notes concerning measuring sequence NOTICE Measuring error is possible. Start measuring block only when interference‐free transmission with receiver is guaran‐ teed. (signal level Error = High) Installation instructions IC56 Installation instructions IF59 V2A | 04/2018 © by Blum‐Novotest... -
Page 29: Maintenance
• Keep the transparent ring clean. • Check the bellows on damages and clean it regularly and carefully with a brush. Cleaning of the transparent ring NOTICE Damage of the measuring system by a short circuit is possible Aggressive liquids may destroy seals and damage transparent windows. Do not clean the measuring system by using aggressive detergents! Detergents may not contain aggressive components, that can damage plastics or rubber parts (e.g.: acetone, alcohol, ethanol, methanol, cleaning benzine, solvents, ...). Detergents must have a ph‐level of 5 ... 9. Please do not use any detergents containing abrasive substances (e.g.: cleansing milk or scouring powder)! Strictly do always use a soft, clean cloth to clean. Please contact us if you have any questions! We also have solutions for special applications. Exchange of the external bellows NOTICE Pollution and damage to the measuring mechanism Only exchange the external bellows. The inner bellows may not be detached from its position. In case of damage to the inner bellows, please resend the probe for repair. NOTICE Pollution and damage to the measuring mechanism The bellows of the following devices is allowed to be exchanged by Blum‐Novotest only: TC52, TC52 LF, TC52 T, TC54‐10 LF, TC76 LF In case of damage to the bellows, please return the measuring system for repair. © by Blum‐Novotest V2A | 04/2018... - Page 30 Maintenance Fig. 6‐1 (30) Front ring (33) Internal bellows (31) External bellows (34) Measuring mechanism (32) Centring ring (E) Mounting tool Fig. 6‐2 (30) Front ring (34) Measuring mechanism (31) External bellows (35) O‐ring (32) Centring ring (E) Mounting tool (33) Internal bellows V2A | 04/2018 © by Blum‐Novotest...
- Page 31 Maintenance Fig. 6‐3 (30) Front ring (33) Internal bellows (31) External bellows (34) Measuring mechanism (32) Centring ring (E) Mounting tool 1. Clean the measuring system. Remove the stylus (see chapter 4.4). Therby, use the interlock‐ ing disk or the mounting tool. 2. Unscrew the front ring by using the mounting tool. 3. Carefully remove the outer bellows without twisting the measuring mechanism. 4. Grease slightly the new bellows at the contact surface to the groove. 5. Carefully mount the new bellows without twisting the measuring mechanism. Please take care of plane supporting surface of the bellows. The bellows must click to the groove on the measuring mechanism. TC51: Make sure the O‐ring is in its correct position. 6. Mount the front ring by using the mounting tool. 7. Mount the stylus respectively the probe contact and the chip protection (see chapter 4.4). Therby, use the interlocking disk or the mounting tool. © by Blum‐Novotest V2A | 04/2018...
-
Page 32: Troubleshooting
Troubleshooting 7. Troubleshooting Keys Error = Error message = Error description = Check the following points = Remedy / Workaround Error LED Status red LED Status shines red. Check batteries. Insert new batteries. Error LED Status undefined Undefined flashing or flickering of LED Status. Check batteries. Insert new batteries. Error LED Status after battery change LED Status changes from green to violet while inserting the batteries without actuating the measuring system. LED Status flashes red. Control sends signal "deflected" without actuating the measuring system. No pressure compensation after transport by airfreight V2A | 04/2018 © by Blum‐Novotest... - Page 33 Troubleshooting Error LED Status after battery change Provide pressure compensation: 1) Untighten the screws at the battery compartment lid. 2) Pull back both screws and remove the battery compartment lid. 3) Loosen the setscrew (at least with 2 revolutions). 4) Deflect stylus several times in Z‐direction. Wait for approx.1 minute. 5) Then tighten the setscrew again. 6) Put in the battery compartment lid precisely and mount it (M = 0.7 Nm). Thereby, please check the O‐rings and grease it, if necessary. Fig. 7‐1 (40) Setscrew Error LED Status flashes green‐blue resp. green‐orange Probe system: LED Status flashes green‐blue resp. green‐orange. IR receiver: LED Receive IR off. Probe does not respond to M‐Code (switch‐on). Check wiring and switch‐on command on the IF59: (IF59 X1: Pin 3, Pin 4, Pin 5) Check programming of the probe (Mode TC ‐ Mode DUO) © by Blum‐Novotest V2A | 04/2018...
-
Page 34: Order Numbers
Order numbers 8. Order numbers Use original parts and accessories by Blum‐Novotest only. Tool holder BTH 50 Type L[mm] Order number HSK‐A 40 144376 HSK‐A 50 144380 HSK‐A 63 144383 HSK‐A 80 144391 HSK‐A 100 144372 HSK‐E 40 144377 HSK‐E 50 144381 HSK‐E 63 144385 HSK‐F 40 144378 HSK‐F 63 144386 SK 30 144396 SK 40 144397 SK45 144399 SK 50 144400 BT 30 144406 BT 40 144407 BT 50... - Page 35 144486 MAS‐BT 50 144488 VDI20 144494 VDI25 144496 VDI30 144498 VDI40 144500 VDI50 144502 Polygonal shaft C4 144576 Polygonal shaft C5 144579 Polygonal shaft C6 144582 Coolant pipe for tool holder HSK‐A / HSK‐E Type Order number HSK 25 144374 HSK 32 144375 HSK 40 144379 HSK 50 144382 HSK 63 144387 HSK 80 144395 HSK 100 144373 © by Blum‐Novotest V2A | 04/2018...
- Page 36 Order numbers Touch probe TC50 141745 Touch probe TC51 142076 Touch probe TC52 142174 Basic device TC53‐10 142444 Basic system TC53‐30 142462 Touch probe TC54‐10 142480 Spare and wear parts Spare and wear parts are not subject to warranty. Accessory for probe Ø 63 Accessory set for probe 143725 3,6V TC50, TC51 3,6V Accessory set for probe 143726 3,6V 3,6V TC53‐30 Battery for probe Ø63 / Bore gauge 170407 Saft Lithium LS14500 (AA 3,6 V) 2600 mAh, 2 pcs required Bellows (5 pieces) 143724 Accessory for probe Ø 25/40 Accessory set for 143735 3,6V Touch probe 3,6V TC54‐10, TC53‐10, TC52 Accessory set for ...
- Page 37 Order numbers Styli for probe TC50 / TC51 Ceramic L [mm] DK [mm] 143411 143412 143413 143414 143415 143416 143417 143418 143419 143420 143421 143422 143423 143424 143425 143426 143427 143428 143429 143430 143431 143432 143433 143435 Carbide L [mm] DK [mm] 143522 143523 143524 143525 143526 143527 143528 143529...
- Page 38 Order numbers Styli for probe TC51 Stainless steel L [mm] D [mm] L1 = 50 mm D1 = 6 mm 143570 L2 = 7.5 mm D2 = 3 mm Styli for probe TC52 / TC54‐10 / TC76 Ceramic L [mm] DK [mm] 143743 143744 143745 143746 143747 143748 143749 143750 143751 143752 143753 143754 143755 143756 143757 143758 143759 143760 V2A | 04/2018 © by Blum‐Novotest...
- Page 39 L [mm] DK [mm] 143766 143767 143768 143769 143770 143771 143772 143773 143774 143775 143776 143777 143778 143779 143780 143781 143782 143783 143784 143785 143786 143787 143788 143789 143790 143791 143792 143793 143794 143795 143796 143797 143798 143799 © by Blum‐Novotest V2A | 04/2018...
- Page 40 Order numbers Styli for probe TC54‐10 / TC76 Carbide L [mm] Adapter 144093 Stylus 144122 144116 144115 144117 144114 144119 144118 144120 (1) Adapter (2) Stylus V2A | 04/2018 © by Blum‐Novotest...
-
Page 41: Shipping Instructions / Storage
Shipping instructions / storage 9. Shipping instructions / storage NOTICE If you return the measuring system for repair, please enclose a detailed error description. The measuring system has to be returned in the original packing only. The packing is not allowed to deflect the measuring system. The measuring system should be packed shock and pollution protected. Service order Please complete this repair order answering all questions in detail and attach it to the system. It will be more cost effective for both parties if we have all the information and will ensure a prompt repair service. Blum‐Novotest GmbH Kaufstr. 14, 88287 Gruenkraut ‐ Germany Tel. +49 751 6008‐0, Fax. +49 751 6008‐156 Company: Department: Contact: Address: Phone: Fax: Email: Measuring system type, serial No.: Machine type, manufacturer: Description of defect: © by Blum‐Novotest V2A | 04/2018... -
Page 42: Ec Declaration Of Incorporation
EC Declaration of Incorporation 10.EC Declaration of Incorporation acc. to the EC Machine Regulations 2006/42/EC in the edition from 17 May.2006 We hereby confirm that the subsequently following components are defined for the installation into other machines and that they are in accordance with the following safety requirements of the EC regulations. Commissioning is not allowed until it is ascertained that the machines, in which the compo‐ nents are installed, are in accordance with the EC regulations 2006/42/EC. The relevant technical information is compiled acc. to annex VII part B and, where appropriate, we will send the information concerning the components to the different countries. The indus‐ trial property rights of Blum‐Novotest GmbH will remain unaffected. Component name TC50 | TC51 | TC52 | TC53‐10 | TC53‐30 | TC54‐10 | TC76 Probe for workpiece measurement Safety requirements 1.5.1 2006/42/EC, Annex I Applied standards: EC‐Regulations: 2014/30/EU 2014/35/EU Applied harmonized standards: EN 61000‐6 EN 60204‐1 EN ISO 12100 Applied national standards: DIN VDE 0100 DIN VDE 0113 Authorised representative for technical information: Blum‐Novotest GmbH Kaufstr. 14 88287 Gruenkraut, Germany V2A | 04/2018 © by Blum‐Novotest... -
Page 43: Service
Service 11.Service Headquarters: Worldwide: Blum‐Novotest GmbH Kaufstr. 14 88287 Grünkraut, Germany Tel.:+49 751 6008‐0 Fax:+49 751 6008‐156 www.blum‐novotest.com Vertrieb/Sales: sales@blum‐novotest.com Service: service@blum‐novotest.com Hotline: Vertrieb/Sales: Tel.:+49 751 6008‐200 Tel.:+49 751 6008‐202 Service: © by Blum‐Novotest V2A | 04/2018...
