2. Make sure that the power cord is unplugged.
Remove the tie securing the Upright Wire (83) to
the front of the Base (93).
Next, identify the Right Upright (84). Have a sec-
ond person hold the Right Upright near the Base
(93).
See the inset drawing. Tie the wire tie (A) in
the Right Upright (84) securely around the end
of the Upright Wire (83). Then, insert the Upright
Wire into the lower end of the Right Upright as
you pull the other end of the wire tie through the
Right Upright.
3. Lay the Right Upright (84) near the Base (93).
Press the Grommet (86) into the square hole (B)
in the Right Upright. Make sure not to pinch
the ground wire (C).
If there is a screw (D) preattached to the Right
Upright (84), remove and discard it.
Then, attach the ground wire (C) to the Right
Upright (84) with a #8 x 1/2" Silver Screw (13).
2
A
83
84
93
3
93
C
9
83
A
84
13
86
D
B
84
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the PRO 2000 and is the answer not in the manual?
Questions and answers
When I press any button it just beeps at me but never turns on
Your Pro-Form PRO 2000 may not turn on due to the following reasons:
1. Power Cord – Ensure the power cord is properly plugged into a grounded outlet.
2. Extension Cord – If using an extension cord, it must be a 3-conductor, 14-gauge (2 mm²) cord no longer than 5 ft. (1.5 m).
3. Key Not Inserted – Make sure the key is inserted into the console.
4. Tripped Power Switch – Check the power switch near the power cord. If it has tripped (protruding), wait five minutes and press it back in to reset.
If the issue persists, further troubleshooting may be needed.
This answer is automatically generated
