Pro-Form Pro 1500 User Manual

Hide thumbs Also See for Pro 1500:
Table of Contents

Advertisement

Quick Links

Model No. PETL14618.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form Pro 1500

Summary of Contents for Pro-Form Pro 1500

  • Page 1 Model No. PETL14618.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 21. The treadmill is capable of high speeds. frame securely in the storage position. Do Adjust the speed in small increments to not operate the treadmill while it is folded. avoid sudden jumps in speed. 26. Do not change the incline of the treadmill by 22.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® PRO 1500 treadmill. The PRO 1500 treadmill offers an manual. To help us assist you, please note the product impressive selection of features designed to make your model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (83) to the front of the Base (93). Next, identify the Right Upright (84). Have a second person hold the Right Upright near the Base (93).

  • Page 9: Make Sure Not To Pinch The Upright Wire (83

    4. Hold the Right Upright (84) against the Base (93). Make sure not to pinch the Upright Wire (83). Attach the Right Upright (84) with two 3/8" x 2 3/4" Screws (23), two 3/8" x 1 1/4" Screws (20), and four 3/8" Star Washers (25) as shown;...
  • Page 10 6. Attach the two Handrails (74) to the Right and Left Uprights (84, 91) with the four 5/16" x 2" Screws (2) that you removed in step 5 and four 5/16" Star Washers (8); start all four Screws, and then tighten them. Be careful not to pinch the Upright Wire (83) on the right side.
  • Page 11 8. See the inset drawing. Connect the Upright Wire (83) to the console wire (H). The connec- tors should slide together easily and snap into place. If they do not, turn one connector and try again. IF YOU DO NOT CONNECT THE CONNECTORS PROPERLY, THE CONSOLE MAY BECOME DAMAGED WHEN YOU TURN ON THE POWER.
  • Page 12 10. IMPORTANT: To avoid damaging the Pulse Crossbar (80), do not use power tools, and do not overtighten the #10 x 3/4" Screws (6) or the 1/4" x 5/8" Screws (99). Tighten two 1/4" x 5/8" Screws (99) with two 1/4"...
  • Page 13 12. Attach the Left Handrail Bottom Cover (75) to the left Handrail (74) with two #8 x 3/4" Truss Head Screws (24); start both Truss Head Screws, and then tighten them. Be careful not to over- tighten the Truss Head Screws. Attach the Right Handrail Bottom Cover (82) to the right Handrail (74) as described above.
  • Page 14 14. Carefully slide the Upright Crossbar (76) between the Right and Left Uprights (84, 91). Attach the Upright Crossbar with four 5/16" x 3/4" Screws (1); start all four Screws, and then tighten them. 15. Attach the Tray (97) to the Upright Crossbar (76) with four #8 x 3/4"...
  • Page 15 16. Raise the Frame (52) to the upright position. IMPORTANT: Have a second person hold the Frame until step 18 is completed. Orient the Latch Crossbar (78) as shown. Make sure that the “This side toward belt” sticker (J) is facing the treadmill. Attach the Latch Crossbar (78) to the brackets (K) on the Frame (52) with the two 5/16"...
  • Page 16 18. Remove the 5/16" Nut (9) and the 5/16" x 2 1/4" Bolt (4) from the bracket on the Latch Crossbar (78). Align the upper end of the Storage Latch (56) with the bracket on the Frame (52), and insert the 5/16"...
  • Page 17 20. Attach the Tablet Holder (100) to the console assembly (G) with four M4 x 16mm Screws (3); start all four Screws, and then tighten them. Do not overtighten the Screws. 21. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic on the treadmill decals, remove the plastic.

  • Page 18: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 20. To use the man- ual mode, see page 20. To use an onboard workout, see page 22. To connect your tablet to the console, The treadmill console offers a selection of features designed to make your workouts more effective and see page 23.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room temperature before you turn on the power. If you See HOW TO TURN ON THE POWER at the left.
  • Page 21 4. Change the incline of the treadmill as desired. Vertical Distance (VRT FT or VRT M)—The distance you have walked or run in vertical feet or To change the incline of the treadmill, press the vertical meters. Incline increase and decrease buttons or one of the numbered incline buttons.
  • Page 22 6. Measure your heart rate if desired. 8. When you are finished exercising, remove the key from the console. You can measure your heart rate using either the handgrip heart rate monitor or a compatible heart Step onto the foot rails, press the Stop button, rate monitor.
  • Page 23 HOW TO CONNECT YOUR TABLET TO THE At the end of each segment, the speed and/or incline setting for the next segment will flash in the CONSOLE display to alert you if the setting is about to change. The treadmill will then automatically adjust to the The console supports Bluetooth connections to tab- speed and incline settings for the next segment.
  • Page 24 4. Record and track your workout information. THE SETTINGS MODE Follow the instructions in the iFit–Smart Cardio 1. Select the settings mode. Equipment app to record and track your workout information. To select the settings mode, press the Settings button. The first settings screen will appear in the 5.
  • Page 25 Display Test—This screen is intended to be used Contrast Level—The currently selected contrast by service technicians to identify whether the level will appear in the display. Press the Incline display is working correctly. increase and decrease buttons to adjust the contrast level.
  • Page 26 HOW TO USE THE SOUND SYSTEM HOW TO USE THE TABLET HOLDER To play music or audio books through the console IMPORTANT: The tablet holder (E) is designed for use with most full-size tablets. Do not place sound system while you exercise, plug a 3.5 mm male any other electronic device or object in the tablet to 3.5 mm male audio cable (not included) into the jack on the console and into a jack on your personal audio...

  • Page 27: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 28: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal perfor- a. Check the power switch (see drawing c at the left). mance and to reduce wear. Inspect and properly tighten If the switch has tripped, wait for five minutes and all parts each time the treadmill is used.
  • Page 29 Locate the Reed Switch (118) and the b. If the walking belt is overtightened, treadmill per- Magnet (117) on the left side of the Pulley (51). formance may decrease and the walking belt may Turn the Pulley until the Magnet is aligned with the become damaged.
  • Page 30 SYMPTOM: The walking belt is not centered SYMPTOM: The tablet holder does not stay in place between the foot rails a. Rotate the tablet holder (C) until it faces backward. a. IMPORTANT: If the walking belt rubs against Then, tighten the indicated screw (D) slightly until the foot rails (B), the walking belt may become the tablet holder stays in place when it is rotated to damaged.

  • Page 31: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 32 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 33 NOTES...

  • Page 34: Part List

    PART LIST Model No. PETL14618.0 R1218A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Drive Roller/Pulley 5/16" x 2" Screw Frame M4 x 16mm Screw 5/16" x 2 1/4" Bolt Drive Motor #8 x 3/4" Screw Motor Belt #10 x 3/4"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Base Pad Incline Stop Bracket Console Wire Tie Wire Tie Console Ground Wire 7/32" Washer 1/4" x 1" Screw Motor Bracket Pulse Bar Clamp Fan Cover Magnet Fan Housing Reed Switch Console Clamp Motor Bushing Filter #8 Nut...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL14618.0 R1218A...
  • Page 37 EXPLODED DRAWING B Model No. PETL14618.0 R1218A...
  • Page 38 EXPLODED DRAWING C Model No. PETL14618.0 R1218A...
  • Page 39 EXPLODED DRAWING D Model No. PETL14618.0 R1218A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
