8. See the inset drawing. Connect the Upright
Wire (83) to the console wire (H). The connec-
tors should slide together easily and snap
into place. If they do not, turn one connector
and try again. IF YOU DO NOT CONNECT THE
CONNECTORS PROPERLY, THE CONSOLE
MAY BECOME DAMAGED WHEN YOU TURN
ON THE POWER. Then, remove any wire ties
(I) from the Upright Wire.
9. Insert the wires (H) into the top of the Right
Upright (84).
Next, locate the Wire Tie (102) included with the
hardware. Insert the Wire Tie through the small
hole in the side of the Right Upright (84). Then,
tighten the Wire Tie around the wires (H), and
cut off the end of the Wire Tie.
8
I
9
84
12
H
83
H
83
H
102
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the PRO 2000 and is the answer not in the manual?
Questions and answers
When I press any button it just beeps at me but never turns on
Your Pro-Form PRO 2000 may not turn on due to the following reasons:
1. Power Cord – Ensure the power cord is properly plugged into a grounded outlet.
2. Extension Cord – If using an extension cord, it must be a 3-conductor, 14-gauge (2 mm²) cord no longer than 5 ft. (1.5 m).
3. Key Not Inserted – Make sure the key is inserted into the console.
4. Tripped Power Switch – Check the power switch near the power cord. If it has tripped (protruding), wait five minutes and press it back in to reset.
If the issue persists, further troubleshooting may be needed.
This answer is automatically generated
