12. Attach the Left Handrail Bottom Cover (75) to the
left Handrail (74) with two #8 x 3/4" Truss Head
Screws (24); start both Truss Head Screws,
and then tighten them. Be careful not to over-
tighten the Truss Head Screws.
Attach the Right Handrail Bottom Cover (82)
to the right Handrail (74) as described above.
13. Identify the Left and Right Trays (94, 32). Attach
the Trays to the console assembly (G) with six
#8 x 3/4" Truss Head Screws (24); start all six
Truss Head Screws and then tighten them.
Do not overtighten the Truss Head Screws.
12
74
75
24
13
32
24
24
14
74
82
24
G
94
24
24
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the PRO 2000 and is the answer not in the manual?
Questions and answers
When I press any button it just beeps at me but never turns on
Your Pro-Form PRO 2000 may not turn on due to the following reasons:
1. Power Cord – Ensure the power cord is properly plugged into a grounded outlet.
2. Extension Cord – If using an extension cord, it must be a 3-conductor, 14-gauge (2 mm²) cord no longer than 5 ft. (1.5 m).
3. Key Not Inserted – Make sure the key is inserted into the console.
4. Tripped Power Switch – Check the power switch near the power cord. If it has tripped (protruding), wait five minutes and press it back in to reset.
If the issue persists, further troubleshooting may be needed.
