16. Raise the Frame (52) to the upright position.
IMPORTANT: Have a second person hold the
Frame until step 18 is completed.
Orient the Latch Crossbar (78) as shown. Make
sure that the "This side toward belt" sticker
(J) is facing the treadmill.
Attach the Latch Crossbar (78) to the brackets
(K) on the Frame (52) with the two 5/16" x 1 1/4"
Screws (29) and two 5/16" Star Washers (8).
17. Remove the 5/16" Nut (9) and the 5/16" x 1 3/4"
Bolt (7) from the bracket on the Base (93).
Next, orient the Storage Latch (56) as shown.
Attach the lower end of the Storage Latch (56)
to the bracket on the Base (93) with the 5/16" x
1 3/4" Bolt (7) and the 5/16" Nut (9).
Then, raise the Storage Latch (56) to a vertical
position, and remove the tie (L).
16
K
8
29
17
16
52
J
78
K
8
29
L
56
9
93
7
