- Page 1 User's Guide Compaq V1000 Color Monitor...
- Page 2 © 1998 Compaq Computer Corporation. All rights reserved. Printed in Taiwan. Compaq, Deskpro, and QVision are registered in the U.S. Patent and Trademark Office. Microsoft, MS-DOS, Windows, Windows NT, and other names of Microsoft products referenced herein are trademarks or registered trademarks of Microsoft Corporation.
-
Page 3: Product Features
1 English Product Features The Compaq V1000 Color Monitor includes the following features: 21-inch CRT that has superior brightness and uniformity with a 20-inch (50.8 cm) diagonal viewable image size Twenty-two preset display resolutions including 1800 × 1440 at 60 Hz... -
Page 4: Information Files
Compaq Deskpro and Compaq Workstation computers are capable of supporting a monitor that weighs up to 100 lbs. If you are not using a Compaq Deskpro or Workstation, place the monitor directly on a desktop or other work surface. 2. Connect one end of the monitor signal cable 2 to the monitor, and the other end to the 15-pin connector on the rear panel of the computer and tighten the screws. - Page 5 3. Connect the monitor power cord 1 to the rear panel of the monitor, then plug the other end into an electrical outlet that is easily accessible and close to the monitor. WARNING: To reduce the risk of electric shock or damage to your equipment: Do not disable the power cord grounding plug.
- Page 6 1. Connect the five BNC connectors to the monitor. Push in and twist the connectors clockwise until they are locked into place. The color of the wires may vary, so refer to the manufacturer's instructions included with the BNC connectors. The connectors are color coded from left to right in the following order: 1 White for horizontal sync (H) 2 Black for vertical sync (V)
- Page 7 USB signal cable to the computer. Use Connectors USB-compatible plug and play devices to the monitor. IMPORTANT: These USB connectors are not designed for use with high-power USB devices such as video cameras, scanners, etc. Compaq recommends connecting high-power USB devices directly to the computer. English...
-
Page 8: Adjusting Screen Quality
USB cables. Low-power USB devices usually have an attached cable that measures about 3 meters. Most USB-connected devices will operate with Compaq computers using Microsoft Windows 95, OSR 2.1. If a USB- connected device fails to operate, it may require a special device driver that is not supplied with this version of Microsoft Windows. -
Page 9: Operating The Monitor
Operating the Monitor Front Panel Controls Icon Control Function Contrast Dial Adjusts Contrast. Brightness Dial Adjusts Brightness. Selects the computer signal to input to the monitor Computer Select when two computers are connected to the monitor at Switch the same time. 1. -
Page 10: On-Screen Display Settings
On-Screen Display Settings The adjustments for screen settings are located in the on-screen display (OSD) and can be viewed in one of six available languages. The OSD contains adjustments for the following functions: Main Menu Level Menu Level Menu Size and Position Width Adjustment scale Horizontal Position... - Page 11 How to Adjust Settings To launch the on-screen display Main Menu: 1. Press the Select button 1 on the monitor front panel. The Main Menu will display on the monitor screen. 2. To select an item from the Main Menu, scroll down by pressing the Minus (-) button 2 located on the monitor front panel.
- Page 12 8. To exit from the on-screen menu, select Exit from the Main Menu. If the display is a second- or third-level menu, select Save and Return or Cancel, then select Exit from the Main Menu. The on-screen display is easy to use, just follow the instructions on the screen.
- Page 13 You must set the current local time before you reset the time for SLEEP Time or ON Time. 5. Press the Menu button once to enter the adjustment mode for hours—the hours will blink. 6. Press the Minus or Plus buttons to adjust the hour. 7.
-
Page 14: Preset Display Resolutions
Display Resolutions The display resolutions listed below are the most commonly used modes and are set as factory defaults. This monitor automatically recognizes these preset modes when they are requested by a software program and will provide the user with a properly sized and centered display. Preset Display Resolutions Modes Resolutions... -
Page 15: Energy Saver Feature
The video controller signal may occasionally call for a mode that is not preset if: You are not using a Compaq standard graphics adapter. You are not using a preset mode. If this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen display. -
Page 16: Care And Maintenance
The energy saver features for monitors only work when connected to computers that have energy saver features. Care and Maintenance This section explains how to care for and maintain your Compaq monitor during normal everyday use. Protecting the Monitor To protect your monitor from overheating and other types of damage,... - Page 17 Do not open the monitor cabinet or attempt to service this product yourself. Adjust only those controls that are covered by the operating instructions. If the monitor is not operating properly or has been dropped or damaged, contact your Compaq authorized dealer, reseller, or service provider. Cleaning the Monitor To clean the monitor, follow these steps: 1.
-
Page 18: Agency Regulatory Notices
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations. - Page 19 Règlement sur le matériel brouilleur du Canada. German Ergonomics Notice Compaq Computers, when tested with the Compaq PE1140 Series monitors, were evaluated and found compliant to the requirements of ZH 1/618 (German Safety Regulations for Display Work Places in the Office Sector).
- Page 20 EPA E program. As an E NERGY NERGY Partner, Compaq Computer Corporation has determined that this product meets the E guidelines for energy efficiency. Specific NERGY details on using the Energy Saving features can be found in the energy saver or power management section of the computer manual.
-
Page 21: Specifications
Specifications Compaq V1000 Color Monitor Display 21-in Shadow Mask FS CRT 53.3 cm Viewable Image Size 20-in diagonal 50.8 cm Face Treatment Antireflective/antistatic coatings Weight (Unpacked) 64.9 lbs 29.5 kg Maximum Dimensions Height 19.9 in 50.6 cm Depth 20.0 in 50.7 cm... - Page 22 Acceptable Signal Transmission Schemes The following input sync information is for users who connect this monitor to a non-Compaq computer. You may need to provide your own cables or connectors to the computer. If you are a nontechnical user and need more information than is provided, contact a Compaq authorized dealer, reseller, or a service provider.
-
Page 23: Power Cord Set Requirements
Power cord sets must meet the requirements of the country where you use the monitor. For more information on power cord set requirements, contact your Compaq authorized dealer, reseller or service provider. General Requirements The requirements listed below are applicable to all countries: 1. -
Page 24: Country-Specific Requirements
Country-Specific Requirements Power Cord Set Requirements: By Country Accredited Agency Applicable Note Country Numbers Australia EANSW Austria Belgium CEBC Canada China CCEE Denmark DEMKO Finland FIMKO France Germany Italy Japan MITI The Netherlands KEMA Norway NEMKO Singapore PSB or PUB Sweden SEMKO Switzerland...
