User's
Guide
Compaq V710 Color Monitor

Advertisement

Table of Contents
loading

Related Manuals for Compaq V710

Summary of Contents for Compaq V710

  • Page 1 User’s Guide Compaq V710 Color Monitor...
  • Page 2 The information in this guide is subject to change without notice. © 2000 Compaq Computer Corporation. Except for use in connection with the accompanying Compaq prodcut, no part of this guide may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation.

  • Page 3: Safety Instructions

    Safety Instructions Before connecting the AC power Put your monitor in a location with cord to an outlet, make sure the low humidity and a minimum of voltage designation on your monitor dust. corresponds to the local electrical Do not expose the monitor to rain or supply.

  • Page 4: Connecting Your Monitor

    Compaq V710 Color Monitor Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Driver and Documentation CD-ROM Guide Power Cord EXIT EXIT MENU MENU MENU Warranty card Monitor Stand (Not available in all locations)

  • Page 5: Front Panel

    Compaq V710 Color Monitor Front Panel EXIT MENU EXIT MENU MENU EXIT ( ) button Brightness feature controls. (See the Closes the on-screen menu. It is also used section below on Direct Access Buttons.) to return to the previous menu when using the on-screen menu system.

  • Page 6: Operation

    Operation On-screen Menu System Your monitor has an on-screen menu system, accessed by the buttons on the front of your monitor, that allows you to adjust characteristics of the screen image. Display changes are indicated by on-screen adjustment icons. Some functions have sub-menus. Push the menu button to display the main menu.
  • Page 7 Operation Icon Monitor Function Control Brightness Brightness Background brightness of screen. -– Decreases brightness + Increases brightness Access Function Contrast Contrast Contrast of screen image. -– Decreases contrast + Increases contrast Access Function Horizontal Position H-Position Horizontal screen position. -– Moves screen left + Moves screen right Access Function Vertical Position...
  • Page 8 Operation Icon Monitor Function Control Pincushion Pincushion Straightens screen vertical edges. -– Curves image inward + Curves image outward Access Function Geometry Trapezoid Width of top and bottom of screen. -– Widens bottom of screen Geometry + Widens top of screen Parallelogram Access Function -–...
  • Page 9 Operation Icon Monitor Function Control Language Language -– and + scroll through on-screen language options. English (English/ Deutsch/ Francais/ Italiano Access Function Português/ Español/ Svenska/ Russian/ Exit Menu Korean) Advanced H- Moiré Advanced Corrects for on-screen moiré pattern. Access Function -–...
  • Page 10 Operation Icon Monitor Function Control Zoom Zoom -– Reduces view of display area + Enlarges view of display area Access Function Degauss Degauss Removes color distortion caused by magnetic fields. Do not use more than once in 30 minutes. Access Function Recall Recall Returns monitor to original settings.

  • Page 11: Troubleshooting

    Troubleshooting Before calling for service, check the information in this section to see if you can solve the problem yourself. If you do need assistance, please contact your dealer or refer to the Contacting Customer Support booklet that shipped with this product. There is no screen image  Check to see that both the monitor and the computer are plugged in and turned on.

  • Page 12: Display Modes

    PowerSaver The monitor automatically returns to normal operation when you move the computer's mouse or press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPMS compliant video card installed in your computer.

  • Page 13: Specifications

    Specifications Specifications Model: Compaq V710 Color Monitor Picture Tube • 17” (43 cm) Full square type [16”(40.6 cm )Viewable] • Flat face, 90° Deflection • Dot pitch: 0.20 mm (Horizontal)/0.24mm(Diagonal) • TCO: Multilayer coating ~ anti-static, anti-reflection properties • Medium-short persistence phosphor Synchronization •...

  • Page 14: Agency Regulatory Notices

    Consult the dealer or an experienced radio or television technician for help Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations.

  • Page 15: Canadian Notice

    For questions regarding your product, contact: Compaq Computer Corporation P. O. Box 692000, Mail Stop 530113 Houston, Texas 77269-2000 Or, call - 1-800- 652-6672 (1-800-OK COMPAQ) For questions regarding this FCC declaration, contact: Compaq Computer Corporation P. O. Box 692000, Mail Stop 510101...
  • Page 16 18AWG, and the length of the cord must be between 6 feet (1.8 m) and 12 feet (3.6 m). If you have questions about the type of power cord to use, contact your Compaq authorized service provider. A power cord should be routed so that it is not likely to be walked on or pinched by items placed upon it or against it.
