User's Guide
Compaq V75 Color Monitor
Second Edition (January 1998)
First Edition (November 1997)
Part Number 307716-002
Compaq Computer Corporation
Advertisement
Table of Contents
Related Manuals for Compaq 307713-001 - V 75 - 17" CRT Display
Summary of Contents for Compaq 307713-001 - V 75 - 17" CRT Display
- Page 1 1997, 1998 Compaq Computer Corporation. All rights reserved. Printed in Taiwan. Compaq, Deskpro, and QVision are registered in the U.S. Patent and Trademark Office. Microsoft, MS-DOS, Windows, Windows NT, and other names of Microsoft products referenced herein are trademarks or registered trademarks of Microsoft Corporation.
-
Page 2: Product Features
NGLISH Introduction The Compaq V75 Color Monitor is a microprocessor-based, intelligent scanning monitor that automatically locks in on the most common display modes. This monitor operates most efficiently when used with a Compaq compatible graphics controller. Product Features The monitor features include the following: 17-inch CRT with a 16.0-inch (40.6 cm) diagonal viewable... - Page 3 Compaq Desktop, Portable, and Workstation Products and the Compaq World Wide Web site (www.compaq.com). If the updated Universal Driver Manager that supports the Compaq monitor is not available on the Web site, contact your authorized Compaq dealer or reseller. English...
- Page 4 CD or backup diskettes, contact your Compaq authorized reseller, dealer, or service provider. If you call Compaq to place an order, be sure to have the serial number of your monitor available. The serial number is located on the back of your monitor. This number is necessary for all purchases.
-
Page 5: Setting Up The Monitor
Setting Up the To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices, then Monitor follow these steps: 1. Place the monitor in a convenient, well-ventilated location near your computer. 2. - Page 6 3. Connect the monitor signal cable to the 15-pin connector on the rear panel of the computer and tighten the screws. Be sure the signal cable aligns with the 15-pin connector. Do not force the cable onto the connector or you may damage the signal cable.
- Page 7 CAUTION: This USB connector is not designed for use with high speed USB devices such as a video camera, scanner, etc. Compaq recommends connecting high speed devices directly to the computer. These USB connectors operate as a pass-through system. Your computer must have a USB host controller installed for any USB-connected devices to operate.
-
Page 8: Operating The Monitor
Operating the Monitor Front Control Panel Icon Control Function Contrast Adjusts contrast. Brightness Adjusts brightness. Select Button 1. Launches on-screen display. 2. Selects Function adjustments. 3. Exits menus and on-screen display. Minus Button Selects and adjusts functions. Plus Button Selects and adjusts functions.. Power Saving LED 1. - Page 9 On-Screen Display Settings The adjustments for screen settings are located in the on-screen display (OSD) and can be viewed in one of six available languages. The on-screen Main Menu displays the following seven functions: Size and Position—Adjusts the horizontal and vertical size and position of the screen.
- Page 10 Making Adjustments Using the OSD To make a selection from the on-screen display: 1. Press the Select button on the monitor front panel. The Main Menu will display on the monitor screen. Monitor with On-Screen Display 2. To make a selection from the Main Menu, scroll down by pressing the Minus ( ) button located on the monitor front panel, or by pressing the Plus ( ) button...
-
Page 11: Adjusting Picture Quality
5. Highlight your choice and press the Select button. 6. The third level displays a sizing window for adjusting the selected function. To adjust, press the Minus button to decrease the number of degrees, or press the Plus button to increase the number of degrees. -
Page 12: User Modes
The video controller signal may occasionally call for a mode that is not preset if: You are not using a compatible Compaq graphics adapter. You are not using a preset mode. If this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen display. -
Page 13: Energy Saver Feature
Energy Saver The energy saver feature has three different modes of operation: Feature Full power mode Suspend mode Sleep mode By selecting settings in the computer's Energy Saver utility, you determine the length of inactivity before the monitor goes into suspend or sleep mode. -
Page 14: Care And Maintenance
Care and This section explains how to care for and maintain your Compaq monitor during normal everyday use. Maintenance Protecting the Monitor To protect your monitor from overheating and other types of damage, follow these suggestions: Use only a power source and connection appropriate for this monitor, as indicated on the marking label/back plate. - Page 15 If the monitor is not operating properly or has been dropped or damaged, contact your Compaq authorized dealer, reseller, or service provider. Cleaning the Monitor To clean the monitor, follow these steps: Turn off the monitor and the computer.
-
Page 16: Federal Communications Commission Notice
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations. - Page 17 Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. German Ergonomics Notice Compaq Computers, when tested with the Compaq 623 and 624 Series monitors, were evaluated and found compliant to the requirements of ZH 1/618 (German Safety Regulations for Display Work Places in the Office Sector) in the Text Mode (720 ×...
-
Page 18: Japanese Notice
Monitors that are marked with the Energy Star Logo meet the requirements of the EPA Energy Star program. As an Energy Star Partner, Compaq Computer Corporation has determined that this product meets the Energy Star guidelines for energy efficiency. Specific details on using the Energy Saving features can be found in the energy saver or power management section of the computer manual. -
Page 19: Specifications
PECIFICATIONS Compaq V75 Color Monitor Display 17-in FS CRT 43.18 cm Viewable Image Size (diagonal) 16.0 in 40.6 cm Screen Treatment Antiglare/antistatic coating Approximate Weight (Unpacked) 44 lb 20 kg Maximum Dimensions Height 17.3 in 43.9 cm Depth 17.3 in 43.9 cm... -
Page 20: Connector Pin Assignments
Connector Pin Assignments Signal Cable Connector Signal Red Video Green Video Blue Video Open Return Red Gnd Green Gnd Blue Gnd Reserved (No Pin) Sync Return Open Bidirectional Data (SDA) H-Sync/Composite Sync V-Sync Data Clock (SCL) DDC Signals Color Display Values CIE* Chromaticity Coordinates 0.625 0.340... -
Page 21: Power Cord Set Requirements
Power cord sets must meet the requirements of the country where you use the monitor. For more information on power cord set requirements, contact your Compaq authorized dealer, reseller or service provider. General Requirements The requirements listed below are applicable to all countries: 1. -
Page 22: Country-Specific Requirements
Country-Specific Requirements Power Cord Set Requirements: By Country Accredited Applicable Note Country Agency Numbers Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland FIMKO France Germany Italy Japan MITI The Netherlands KEMA Norway NEMKO Sweden SEMKO Switzerland United Kingdom United States Notes: 1.
