PROGRAMMING THE RADIO

Before Using the Customer Programming Software (CPS)

Before you begin programming, ensure the following:
1. Install the Customer Programming Software (CPS), FVN5051A, in your computer.
2. Use a fully charged radio battery.
3. With the radio initially turned off, properly place radio into Programming Stand,
4. Connect the Programming/Data cable, FLN9636, according to Setup for Radio Pro-
5. Turn radio on by rotating the On/Off knob clockwise. Verify that no display appears on
MTP700 Portable Radio / Detailed Service Manual
PMLN4510.
gramming Figure 5-1. This cable has a switch with two positions "Data" and "Flash".
Set the switch to "Flash" to enable programming.
the radio LCD screen.
Programming/Data Cable
Figure 5-1 Setup for Radio Programming.
PROGRAMMING THE RADIO
To Computer
Serial Port
(COM 1/2)
(FLN9636)
CHAPTER 5
MTP700 Radio
Programming Stand
(PMLN4510)
5 - 1
