encapsulation (Physical Interface)

Syntax
Hierarchy Level
Release Information
Description
Default
Options
Copyright © 2016, Juniper Networks, Inc.
encapsulation (atm-ccc-cell-relay | atm-pvc | cisco-hdlc | cisco-hdlc-ccc | cisco-hdlc-tcc |
ethernet-bridge | ethernet-ccc | ethernet-over-atm | ethernet-tcc | ethernet-vpls |
ethernet-vpls-fr | ether-vpls-over-atm-llc | ethernet-vpls-ppp | extended-frame-relay-ccc
| extended-frame-relay-ether-type-tcc | extended-frame-relay-tcc | extended-vlan-bridge
| extended-vlan-ccc | extended-vlan-tcc | extended-vlan-vpls | flexible-ethernet-services
| flexible-frame-relay | frame-relay | frame-relay-ccc | frame-relay-ether-type |
frame-relay-ether-type-tcc | frame-relay-port-ccc | frame-relay-tcc | generic-services |
multilink-frame-relay-uni-nni | ppp | ppp-ccc | ppp-tcc | vlan-ccc | vlan-vci-ccc | vlan-vpls);
[edit interfaces interface-name],
[edit interfaces rlsq number:number]
Statement introduced before Junos OS Release 7.4.
Statement introduced in Junos OS Release 11.1 for EX Series switches.
Statement introduced in Junos OS Release 12.1X48 for PTX Series Packet Transport
Routers ( flexible-ethernet-services
Specify the physical link-layer encapsulation type. Not all encapsulation types are
supported on the switches. See the switch CLI.
ppp —Use serial PPP encapsulation.
NOTE: Frame Relay, ATM, PPP, SONET, and SATSOP options are not
supported on the EX Series switches.
atm-ccc-cell-relay —Use ATM cell-relay encapsulation.
—Defined in RFC 2684, Multiprotocol Encapsulation over ATM Adaptation Layer 5.
atm-pvc
When you configure physical ATM interfaces with ATM PVC encapsulation, an RFC
2684-compliant ATM Adaptation Layer 5 (AAL5) tunnel is set up to route the ATM
cells over a Multiprotocol Label Switching (MPLS) path that is typically established
between two MPLS-capable routers using the Label Distribution Protocol (LDP).
—Use Cisco-compatible High-Level Data Link Control (HDLC) framing. E1, E3,
cisco-hdlc
SONET/SDH, T1, and T3 interfaces can use Cisco HDLC encapsulation. Two related
versions are supported:
CCC version (
cisco-hdlc-ccc
statement. When you use this encapsulation type, you can configure the
only.
TCC version (
cisco-hdlc-tcc
restrictions, but used for circuits with different media on either side of the connection.
—Use Cisco-compatible HDLC framing on CCC circuits.
cisco-hdlc-ccc
, ethernet-ccc , and ethernet-tcc
)—The logical interface does not require an encapsulation
)—Similar to CCC and has the same configuration
Chapter 13: Configuration Statements
options only).
family
ccc
115
