- Page 1 MAJORITY NEWNHAM Portable DAB/DAB+/FM Radio CB3-DAB-BLK Instructions Guide...
-
Page 2: Table Of Contents
Contents What’s In The Box? ���������������������������������������������������� Instructions Guide ����������������������������������������������������� Basic Operation �������������������������������������������������������� DAB/DAB+ Radio ������������������������������������������������������� DAB/DAB+ Station Information �������������������������������� FM Radio ������������������������������������������������������������������� FM Station Information �������������������������������������������� Clock and Date Setting ��������������������������������������������� Dual Alarm Setting ��������������������������������������������������� Alarm Functions ������������������������������������������������������� Other Functions ������������������������������������������������������� Internal Rechargeable Battery ���������������������������������... - Page 3 Controls And Functions Power/Source Volume Dial +/- Alarm/Sleep 10. Display Screen Info/Menu 11. On/Off Switch Preset 12. DC 5V 1A Power Select/Snooze Connector Scan 13. Charging Light Indicator Previous button 14. 3.5mm Headphone Socket Next 15. Antenna...
-
Page 4: What's In The Box
What’s In The Box? Box Contents 1. Majority Newnham DAB/DAB+ Radio Clock 2. UK Standard Plug DC 5V 1A Power Supply 3. Instructions Guide... -
Page 5: Instructions Guide
Instructions Guide Basic Operation Please note all (Ref.) refer to the Controls and Functions mapping guide on Page 1. Plug the power connector into the back of the system via the port that is labelled as DC 5V (Ref.12). Alternatively, charge the radio for approximately 2.5 hours, using the power cable, to charge the internal battery. - Page 6 Instructions Guide If the radio does not automatically begin scanning, simply press the ‘Scan’ button (Ref.6) to initiate a full scan. Once it is finished, the first available station will begin to play. Now that the DAB stations have been scanned and searched, you can scroll through the available DAB/DAB+ stations by using the ‘Prev’...
-
Page 7: Dab/Dab+ Radio
Instructions Guide DAB/DAB+ Radio In working mode and off standby, press the ‘Power/Source’ button (Ref.1) to switch the mode to DAB Radio. On first use it will automatically scan all stations and save them. Fully extend the antenna (Ref.15) to ensure the best signal is being received for the scan. - Page 8 Instructions Guide How to store a preset radio station To be able to quickly access your favourite DAB stations, you can preset the stations. Up to 10 different preset stations can be set for you to browse between. To store a station as your preset, it is best to be listening to the station at the time.
-
Page 9: Dab/Dab+ Station Information
Instructions Guide DAB/DAB+ Station Information Whilst listening to a DAB/DAB+ station, you can find out station information. Press the ‘Info/Menu’ button (Ref.3) repeatedly to scroll through the following information: Bit Rate: Shows the data rate at which the signal is being transmitted. -
Page 10: Fm Radio
Instructions Guide FM Radio Press the ‘Power/Source’ button (Ref.1) multiple times to switch to FM. The first time you do this, the FM frequency “87.5 MHz’ will be displayed on the screen. Fully extend the antenna (Ref.15). To scan for the available stations with good signal, press the ‘Scan’... - Page 11 Instructions Guide How to set Mono or Stereo Press the ‘Select/Snooze’ button (Ref.5) multiple times to change between Mono and Stereo. The receiver will automatically switch between Mono and Stereo. Playing ‘Strong’ or ‘All’ FM Stations When on FM mode, you can decide if you would like to pick up all stations (even if they do not have a good signal), or just the stations with strong signal.
- Page 12 Instructions Guide How to store a preset radio station To be able to quickly access your favourite FM stations, you can preset the stations. Up to 10 different preset stations can be set for you to browse between. To store a station as your preset, it is best to be listening to the station at the time.
-
Page 13: Fm Station Information
FM Station Information Whilst listening to an FM station, you can find out station information. Press the ‘Info/Menu’ button (Ref.3) repeatedly to scroll through the following information: Signal Strength: Displays a signal bar with the strength of the current station. Time and Date: Displays the time and date. -
Page 14: Clock And Date Setting
Instructions Guide Clock and Date Setting Manually Setting the Time Ensure the unit is in working mode. The time will automatically update after the first time of using DAB radio, but you can still set the time manually as follows: To enter radio settings, press and hold the ‘Info/Menu’... - Page 15 Instructions Guide Manually Setting the Date The date can be changed straight after changing the time. The year will flash on the display screen. To change the date year, press the ‘Prev’ (Ref.7) or ‘Next’ (Ref.8) buttons until the required year is displayed.
-
Page 16: Dual Alarm Setting
Instructions Guide Dual Alarm Setting Alarm 1/Alarm 2 Setting Press (do not hold) the ‘Alarm/Sleep’ button (Ref.5) and “Alarm 1” will be displayed. Press the button twice for “Alarm 2”. To select the alarm, press the ‘Select/Snooze’ button (Ref.5). Once alarm 1 or 2 is selected, OFF will display on the screen. To turn the alarm on, press the ‘Next’... -
Page 17: Alarm Functions
Instructions Guide Alarm Functions Cancel Alarm 1 or Alarm 2 To cancel the alarm, press the ‘Alarm/Sleep’ button (Ref.2) and “Alarm 1” will be displayed. Use the ‘Prev/Next’ buttons (Ref.5/6) to choose “Alarm 1” or “Alarm 2” depending on which alarm you wish to cancel. -
Page 18: Other Functions
Instructions Guide Other Functions Sleep Setting This enables you to programme the radio to switch off at a selection of set times up to 120 minutes from activation. Press and hold the ‘Alarm/Sleep’ button (Ref.2) for 1 second and release. Using the ‘Prev/Next’... - Page 19 Instructions Guide System Reset To erase all setting and preset options, and reset your radio, perform a factory reset. This would also be advisable if you are having any functionality issues with your radio. To perform a factory reset, press and hold the ‘Info/Menu’ button (Ref.3).
-
Page 20: Internal Rechargeable Battery
Instructions Guide Internal Rechargeable Battery Play Time The Newnham has an internal rechargeable battery that has a playtime of 4-6 hours when it is fully charged. This will allow you to take the radio on the go and use it portably. -
Page 21: Specifications
Specifications Specifications Power supply DC 5V 1A and in-built rechargeable battery Mode FM (87.5MHz - 108MHz) DAB/DAB+ (174-240MHz) Output Connector 3.5mm Earphone Socket Aerial Integral Telescope Aerial Dimensions 21 x 6.5 x 18 cm (LxWxH); 599g Warranty All products come with a standard 12 month warranty. All items www.majorityradios.co.uk must be registered on for the... -
Page 22: Safety Information
Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus. - Page 24 www.majorityradios.co.uk...
